High Grey P3.07 P4 Business Indoor Led Signs With 640*480mm Cabinet
High Grey P3.07 P4 Business Indoor Led Signs With 640*480mm Cabinet
High Grey P3.07 P4 Indoor Led Signs For Business With Cabinet Size 640*480mm
Description of indoor fixed led screen
This series is specialized designed for indoor installation products.High resolution, provide better visual effects. Use die casting aluminum for cabinet, compared iron cabinet, it's lighter and better heat dissipation.Fast and easy to install.
Specifications of indoor fixed led screen
| Item | P3.07 | P4 |
| Pixel pitch | 3.076mm | 4mm |
| Module size | 320*160mm | 320*160mm |
| Module resolution | 104×52 | 80×40 |
| Physical density | 105688 dots/㎡ | 62500 dots/㎡ |
| LED type | SMD2020 | SMD2020 |
| Cabinet size | 640*480*59mm | 640*480*59mm |
| Cabinet resolution | 208*156 | 160*120 |
| Cabinet material | Die casting aluminum | Die casting aluminum |
| Maintenance way | Front | Front |
| Best viewing distance | ≥3m | ≥4m |
| Best viewing angle | H: 160°; V:160° | H: 160°; V:160° |
| Driving method (Constant Current) | 1/26 Scan | 1/20Scan |
| Video frame rate | ≥60 Hz | ≥60 Hz |
| Refresh rate | 3840Hz | 3840Hz |
| Brightness | ≥800nits | ≥800nits |
| Grey Level | 12-16bit | 12-16bit |
| Ingress protection | IP43 | IP43 |
| Life Time | >100,000 Hours | >100,000 Hours |
| The rate | <0.0002 | <0.0002 |
Features of indoor fixed led screen
1. Die casting aluminum cabinet size with 640*480*59mm, compared with iron cabinet. It is more light weight and thin.
2. High Definition. can be seen clear even in indoor strong light and can present delicate image .
3. Suitable customed.It can be suitable different shapes and sizes. Flexible and convenient to install and easy maintenance.
4. Long life. more than 100000hours.
Application of indoor fixed led screen
This product is special designed by indoor fixed led display.High definition, can present more exquisite video. Mostly uesed in Stage Performance, Advertising, Shopping Guide.
Why choose KAILITE?
1. Provide 2 years warranty for your order.
2. Lower price. We have own production workplant, no middle price.
3. We have factory in shenzhen, we support online and offline factory tour if you want.
4. We put quality frist. We will conduct product inspection before, during, after production.
After-sell Service:
1) 2 yaers quality guarantee period
2)Providing customer with the loading program, so they can use as soon as they install the led screen,don't need to debug again
3) If you a are newer we will provide free remote control debuggine service and handle the software
FAQ:
1.Q: Do you support customized?
Yes.we support OEM/ODM services.
2. What's your company main products?
We are a screen factory with more than 14 years experience. Our products are rental screen, fixed screen, outdoor billboard screen, hard led module and soft led module etc. We also accept some customized screen like fine pixel pitch screen, curve screen, etc.
3.Q: When can I arrange the production of my product?
While you paid the deposit, we will arrange production.
4: Do you have any certificates?
Yes, the certificates we have is IOS9001 , IOS2000,FCC,RoHS,CE,CCC
