6500Cd Waterproof truck Outdoor LED Display Full Color 1200hz Rate Refresh
6500Cd Waterproof truck Outdoor LED Display Full Color 1200hz Rate Refresh
1) Environment protection, anti-static, dust-proof, good heat dissipation, cost-effective
2) Low electric current,high-bright lamps, saving 35% energy and high efficiency.
3) The brightness is adjustable to meet the need of changing environment.
4) The horizontal and vertical viewing angles are so wide that it is suitable for wide horizontal
5) High refresh rate , high brightness and high contrast which make the screen without smear phenomenon under directly sunlight.
Parameter
| Items | parameter | |
| Pixel Pitch | P10 | P8 |
| Module Resolution(w*h) | 32*16 | 32*16 |
| Pixel Configuration | 1R1G1B(3in1) | 1R1G1B(3in1) |
| Led Encapsulation | SMD3535 | SMD3535 |
| Pixel Density | 10000/m2 | 15625/m2 |
| Driving Method | 1/2 scan | 1/4scan |
| Refresh Frequency | >1200hz | >1200hz |
| Driver IC | Special constant current IC with high refresh rate and high gray scale | |
| Grey Scale | 16.7bit depending on system and configuration | |
| Cabinet Size | 960mm*960mm | |
| While balance Brightness | >6000cd | |
| Color Temperature | 8000(adjustable) | |
| Viewing Angle | Horizontal 140 V120 | |
| Optimal Viewing Distance | >10m | >8m |
| Working Voltage | AC220v/110v | |
| Max Power Consumption/Per module | 30w | 45w |
| Avg Power Consumption | 860w/m2 | |
| Lifetime | 100000 hours | |
| Operating Temperature | -10°-50° | |
| Net Weight/cabinet | 35.0kg | |
| MBTF | >5000 hours | |
Company
SHENZHEN KAILITE OPTELECTRONIC CO.,LTD Building 4, 3rd Floor, Baiwang Second Industrial, BaiMang Village, Xili Town, Nanshan District, Shenzhen China.The company has focused on all kinds of special automobile R&D, manufacturing, sales and service, two special automobile production lines of the company are five series and 100 products. All our products have passed all kinds of national testing and certificates,including safety testing,waterproof testing,dimming testing,EMC testing,heavy metal content testing,and high/low-temperature testing.and obtained CE,UL,CCC,Rohs certificate.
Why choose us?
1) Your question will be replied in 12 hours.
2) You will be obtained the best service from us.You are importance for us like our other clients.
3) You will feel that all our worker do the work happily if you come to visit our factory cause we love to select the staffs who love this job and respect their job.
4) You will be save more time.We have a experienced team to solute problem.Because we have done many case,we have meet many difficult but those difficult made us strong and now we could easy to due with any problem quickly.
FQA
Q1: How do I know which pixel do I need?
A1: For example, the viewing distance of your led display is about 10 meters, then P10 is recommended; if it is 20 meters, then P20 is recommended.
Q2: What's your package and shipping way?
A2: Goods are packed with wooden case or flight case; delivered by air shipping or sea shipping
Q3: What is the difference between real pixel LED display and virtual pixel LED display?
A3: With the virtual pixel technology, the outdoor led display screen will appear a more clear vision. Theoretically the resolution will be 4 times of a real pixel technology outdoor led display screen.
Front service module and rear service module.
