P5 P6 P8 P10 P12 outdoor LED video wall screen display LED advertising billboard adapt to hot and cold weather
P5 P6 P8 P10 P12 outdoor LED video wall screen display LED advertising billboard adapt to hot and cold weather
P5 outdoor LED display screen
1. High brightness, ≥6000CD/m2
2. IP65 grade, all weather available
3. High referesh rate, ≥1920Hz
4. Gray scale ≥65536
Adopt superior quality SMD 3 in 1 LED lamp, gorgeous color performance.
High brightness LED lamps with wide viewing range and low driving current, consuming less power.
Specification
|
Pixel Pitch
|
5mm
|
Pixel Density
|
40000 dot/m2
|
|
Pixel Configuration
|
SMD3535
|
Module Size
|
160mm*160mm
|
|
Brightness
|
≥6500CD/m2
|
Cabinet Size
|
960mm*960mm
|
|
Refresh Rate
|
≥1920Hz
|
Weight
|
38kg/m2
|
|
Control Mode
|
Synchronized control
|
Drive Method
|
1/8 scan
|
|
Viewing Angle
|
H:140° V:120°
|
Working Voltage
|
AC 220V / AC 110V
|
|
Max. power consumption
|
750W/m2
|
Ave. power consumption
|
300W/m2
|
Smart design LED cabinet
IP rating: Waterproof level IP65 (front),Waterproof level IP54 (back), fearless of any weather conditions.
Cooling system: Scientific structure design make sure enough space with high efficient fans increase dissipation capability, ensure the stability and reliability even for long time continuous use, and prolong the lifespan of the led display.
Plywood case packing
3~4pcs cabinets/box
With PE foam protection
Safe & reliable
SMD 3535 LED lamp
1. Pin internal bending, multiple waterproof, high reliability.
2. White frame, improve brightness;Dumb smooth process, inhibition of reflection.
LED module
Mask material: PC + glassfiber
Excellent waterproof and dust effects, using irrigation methods sealing glue.
Application
