P5 Big Outdoor Full Color Led Display Module 160mm X 160mm For Business
P5 Big Outdoor Full Color Led Display Module 160mm X 160mm For Business
P4/P5/P6/P7/P8/P10/P16/P20 outdoor LED screen adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and blind dots. The screen is manufactured in a waterproof and dustproof design so it can work very well in rain and sunshine. It can be assembled and disassembled very easy, and it is an ideal product for any kind advertisements.
It characterized by perfect vivid image, super brightness, high refresh rate, long life span and stable work, and waterproof, etc.
It is widely used in advertising, sports, industrial enterprise, transportation, stations, terminals, airports, construction, education system and other public places.
Main advantages:
- New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;
- The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;
- Module surface flatness ± 0.2mm, the entire screen has good flatness;
- High uniformity display color;
- For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, which prevents the line of moisture and oxidation.
- Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate;
- Using fishbone bus line greatly reduces the contact problem;
- IP65 grade for high performance waterproof and dustproof capability;
- -25°C – 65°Cworking environment for outdoor display, adapted to the harsh environment.
Technological Parameters
| Items | Parameter |
| Pitch/mm | P5 |
| Module Size/mm | 160x160 |
| Density of Pixels/(dots/m2) | 40000 |
| Pixel composition | 1R1G1B |
| Led encapsulation | SMD2727 |
| Resolution of module | 32x32 |
| Optiminum viewing distance | ≥5m |
| View angle/° | 140H,120V |
| Average power consumption/(w/m2) | 450 |
| Max power consumption(w/m2) | 900 |
| Size of cabinet/mm | 960x960 |
| Resolution of cabinet | 160x160 |
| Weight of cabinet/kg | 55 |
| Driving method | 1/8 scan constant current |
| Refresh rate (HZ/S) | ≥60 |
| Luminance of white balance | ≥6500 nits |
| Operation of enviromental temperature /°C | below 30 to above 50 |
| IP Rating | Front ,IP 65 ; Rear,IP43 |
| Working voltage | 110-220 VAC/ + /-10% |
| Grey scale/color | displaying color≥16.7m(cynchronized) |
| Brightless adjustment | 256 levels of each color(manually),100 levels of each color(automaticlly) |
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition,etc |
| Control system | linsn(sending card,receving card and hubs) |
| Average of non-failure life | over 5,000h |
| Life span | over 100,000h |
| Functionaless dot rate | below 0.0001 |
Warranty:
We guarantee all our displays, modules, parts for two full years. During this time, we will replace or amend all our goods for free if there is something wrong with them. We provide lifetime maintenance and charge only for the raw materials. We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. We also provide the operation manual, software, test report and so on. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided.
Technology Training:
1. We provide the technology training for free, which contains the operation training and maintenance training in the factory.
2. We will send our engineers to your country by negotiation.
Documents and Certification:
1. We provide the operation manual, software, test report and so on.
2. We can also provide all kinds of certification such as CE, UL and so on.
CAD Drawing and Fixing:
1. We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
2. We will send our engineers to your place if we are expected after our negotiation.
Additional service:
We provide you the forwarding information, and some other information ,such as flight box, structure information for your reference for free.
