P5 Portable Indoor Led Video Wall Rental For Concert , Stage Background Led Screen
P5 Portable Indoor Led Video Wall Rental For Concert , Stage Background Led Screen
Features
2.We use black body LED lamp,so the contrast rate is much higher than traditional white body LED lamp.Images on our LED screen looks very sharp.
3. High definition,it can show extremely clear and vivid video,images and texts,looking very high end.
4.High strength,high precision due to that the cabinet material is diecasting aluminum,It is Low Tooling Cost, Molding In One, Stable Size, Short Lead Time.
5.Rapid assembling sets, only 3 steps to lock the adjacent cabinets,can save much labor cost
6. The new structure design enables diversified installation,can be hung-up or stacked
| Numbers | Technical indexes | Specification |
| 1 | Pixel pitch | 5mm |
| 2 | Module size | 320mm×160mm |
| 3 | Module resolution | 64×32 |
| 4 | Module density | 40,000dots/sqm |
| 5 | Pixel configuration | RGB,3 in 1 |
| 6 | Red wavelength | 625±2nm |
| 7 | Green wavelength | 525±2nm |
| 8 | Blue wavelength | 470±2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | 5m---150m |
| 11 | Horizontal viewing angle | 150° |
| 12 | Vertical viewing angle | 120° |
| 13 | Maximum power consumption | 1000W/sqm |
| 14 | Average power consumption | 400W/sqm |
| 15 | Brightness | 10,000cd/sqm,adjustable |
| 16 | Gray scale | 16bits of per color |
| 17 | Color temperature | 12,000K |
| 18 | Driving method | 1/8scanning |
| 19 | Frame frequency | 60Hz |
| 20 | Refresh frequency | 300 Hz |
| 21 | Working voltage | AC220V/110V±10% |
| 22 | IP grade | IP20-45 |
| 23 | Working temperature | -20°C~80°C |
| 24 | MTBF | More than 10,000 hours |
| 25 | Life span | More than 100,000hours |
1)Your inquiry related to our products or price will be replied in 24hrs
2)OEM&ODM,any your customized lightings we can help you to design and put into product
3)Distributoership are offered for your unique design and some our current models
4)Protection of your sales area,ideas of design and all your private information
5)Top Quality+Reasonable Price+Responsible After Service=Successful & Win
1. Can we make any size of outdoor rental led display?
Nope, according the led module size and cabient size, such as p6 outdoor led display, the smallest unit size is: 576*576mm.
2,What's best size of outdoor rental led display?
The best aspect ratio of outdoor rental led display are W16:H9 or W4:H3
3,How to install outdoor rental led display?
We will provide drawing of steel structure or hanging truss,then you can install outdoor led display very easy.
4,How to order outdoor LED display?
Please advise the approx size of outdoor led display you want to have, and the view distance or the pixel you need.
5,How to shipment?
Normally,our outdoor led display will be shipped by air and express (DHL,Fedex.UPS) and in container by sea for the mass order.
