P6 P8 P10 Outdoor Billboard Advertising
high definition giant P3 P4 P5 P6 P8 P10 outdoor billboard advertising equipment LED Display
Product advantages
1) Price Advantage: we have the best competitive price at the market, also have the same even better quality.
2) Quality advantage: From material to finished product, from design to produce, we control all steps
3) Service advantage: Better service at same situation, better cooperation at same service
Application Area
public place:bus,subway, train station, airport, book store, park, exhibtion hall, stadium, museum,buildings, highway, school, meeting room, wedding;
Budiness orginazations: supermarket, shopping mall, hotels, restaurant,hospital;
Financial Orginazations: bank, insurance company, stock company, pawnshop;
Entertainment: theater, clubs, bars,KTV, internet bars;
Specification Paramter
| Item name | P5 |
| Pixel pitch | 5mm |
| Module size(W*H) | 320mmx160mm |
| pixels Density | 40000 dots/sqm |
| Pixel configuration | SMD2727 |
| Pixel resolution | 64*32dots |
| Cabinet size | 960x960mm |
| Quantity of Module | 18pcs |
| Best viewing distance | 5--50 m |
| Best viewing angle | 120°(H) /120°(V) |
| Temperature | storage: - 30°C~+ 70°C |
| working: '- 20°C~+ 60°C | |
| Operation humidity | 10 ~ 90%RH |
| Working voltage | AC110/220V ± 10%,50HZ |
| Aver Consumption | 400 w/sqm |
| Max. Consumption | ≤800 w/sqm |
| Current | ≤20mA(single LED) |
| Operating system | WIN 98/2000/NT/XP/WIN7/WIN8/WIN10 |
| control method | Synchronization/ Asynchronization/3G/WIFI/USB |
| Blind sport rate | <1/10000 |
| Waterproof level | IP65 |
| Drive type | 1/8scan |
| Refresh frequency | ≥1000Hz/s |
| Grey scale/colors | 256 levels of each color(R/G/B)/ 16.7M colors |
| Brightness | ≥6500 cd/sqm |
| Brightness adjustment | 255 levels of each color(R/G/B) by software |
| Video Signal | PAL/NTSC |
| Control system | DVI display card + full color controller card |
| Warranty | 2 full years |
| MTBF | ≥10, 000 hours |
| Life span | ≥70, 000 hours |
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the display, training how to use the software.
* Engineers available to service overseas.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
