 twin screw extrudes machine tandem roller bearing T-81684 factory

A tandem bearing T-81684 is a mechanical component designed with a specialized structure that enables multiple bearing units to work in concert. Its structure belongs to cylindrical roller thrust bearing.This design enables the bearings T-81684 to distribute pressure across multiple units when subjected to impact loads, thereby preventing premature failure caused by overloading at a single point

Bearing factory Number: T-81684
Item code:T-81684
Original place:China LuoYang
Application in mainly equipment: plastic/rubber/pet food double screw extruder gearbox .
Its primary function is to distribute loads and enhance system stability through a tandem arrangement, thereby extending the equipment's service life.
Lubrication:Oil lubrication
Boundary dimension: 23*90*131mm
Bearing shaft diameter:0.9” inch size
Bearing outer diameter:3.54”inch size
Bearing width:5.16 inch size
Tandem stages number:three row stages
Bearing Material:High quality bearing steel
Description:cylindrical roller thrust bearing
UPC/HS code:8482500090
Outer diameter D:90mm
Inner diameter d:23mm
The total height:131mm
Cage type Nylon or Steel or Brass Standard Cage
Precision grade:P5 P4 grade
C :456KN
CO:1605KN
The package:strong carton
Rolling elements:Roller
T-81684:The Axial Forces Are Supported By A three-Stage Tandem Bearing T4AR Combined With An Axial Cylindrical Roller Bearing Of Series 894
Application:gearboxes for single and twin screw extrudes in the rubber and plastics industry.
deep hole drilling equipment friction welding machines.
