Poultry bedding wood shaving making machine factory
Poultry bedding wood shaving making machine factory
Introduct:
Shaving machine, also known as wood shaving machine, wood shaving machine, particle grinder, sawdust shaving machine and so on. Our shaving machine adopts Turkish processing technology. According to China's national conditions, the new chain type shaving machine is improved on the original machine. It can be widely used in the shaving processing of all kinds of wood chips, small sticks, waste wood, leftovers of furniture factories, etc. the shavings produced are uniform in shape, high in yield and complete in specifications.
Working principle:
1. log into the feed port. When starting the machine, turn back and forth, hydraulic pressure, down to the planer plane, after the blade is awesome, blow out the box under the air blow.
2. The wood shaving machine is mainly composed of shell, knife roller, motor, power distribution cabinet, hydraulic system, etc. Its frame is welded with high strength steel plate, which is the support foundation of the whole wood shaving machine.
3. The blade installed on the cutter roller is fixed on the knife roller by the blade bolt made by the professional manufacturer through the pressure block; it can be adjusted up and down within a certain range according to the thickness of the shaving.
4. Cutter roller of wood shaving machine: stop the machine, open the cover and replace the blade.
Technical Parameters:
| Hopper length(cm) | 145 |
| Input material Dia.(cm) | 45 |
| Cutting head(set) | 4 |
| Blade(set) | 6 |
| RPM(r/min) | 4500 |
| Input material length (cm) | 142 |
| Power(kw) | 18.5+18.5+0.37+5.5=42.87kw |
| Shaving depth(mm) | 1-5 |
| Hopper route(mm) | 2200 |
| Feeding speed (hydraulic)(m/min) | 6-15 |
| Dimensions(L*W*H)(cm) | 515*115*180 |
| weight(kg) | 2850 |
| YM-145 | DOC(depth of cut) | |||||
| 1mm | 2mm | 3mm | 4mm | 5mm | ||
|
Speed |
0.10 m/sec | 427kg | 654kg | 880kg | 1107kg | 1334kg |
| 0.15 m/sec | 540kg | 880kg | 1221kg | 1561kg | 1901kg | |
| 0.20 m/sec | 654kg | 1107kg | 1561kg | 2014kg | 2468kg | |
| 0.25 m/sec | 767kg | 1334kg | 1901kg | 2468kg | 3035kg | |
