Salt Spray Test Chamber With Dual Water Supply Mode And ±1C Temperature Departure

Product Description:

Salt Spray Test Chamber (New)

The Salt Spray Test Chamber (New) is a state-of-the-art corrosion testing equipment designed for various industries. With special designs that can be tailored to meet the specific needs of customers, this chamber offers high precision and low maintenance, making it a reliable choice for any testing facility.

Features

• Special designs can be made according to customer needs
• PT 100 temperature sensor with high precision and low maintenance
• Manually and automatically add water according to the customer's installation place
• Easy to use with separate adjustment for greenhouse and laboratory
• Middle air door control connection for perfect structure and easy maintenance
• Energy-saving design with separate control for each test
• Can perform salt spray neutral test, corrosion resistance test, drying test, moisture test, and static test
• Also capable of performing salt spray, dry and wet, and static mixing test with automatic control
• Can automatically cycle spray, continuous spray, and timing spray
• Does not require moving products for salt spray, wet heat, and drying automatic circulation test
• Customizable design for easy use and convenience

Specification parameters:

model	I E4060L	I E4090L	I E40120L	I E40160L	I E40200L
temperature range	0℃ ～ +90℃
temperature departure	±1℃
temperature fluctuation	±0.5℃
temperature uniformity	≦2.0℃
Humidity range	20~100%R.H
Humidity deviation	±2%R.H
relative humidity fluctuation	±2%R.H
humidity uniformity	±3%R.H
Rising and cooling rate	RT →+95℃≤50 min . RT→+0℃≤30 min Salt spray (35℃) dry (60℃.20~30%RH)≤30 min. Dry (60℃, 20-30% RH) and wet (50℃, 95% + / -5% RH) for 15 min. Moistet (50℃, 95% + / -5% RH) salt spray (35℃) for 30 min (immediate spray required after switching).
Test the valid content product	150L	270L	576L	800L	1200L
Internal box size: WxHxD(mm )	600*500*500	900*600*600	1200*1000*600	1600*1000*600	2000*1000*600
carton size: WxHxD(mm )	1780*950*1300	2080*1050*1350	2380*1450*1450	2780*1450*1450	3180*1450*1450
Box structure	● Test chamber box: using imported CPVC polyethylene board, thickness of 8mm, temperature resistance of about 120 degrees. ● Laboratory outer box: using imported CPVC polyethylene board, thickness of 8mm, temperature resistance of about 120 degrees. ● Laboratory sealing cover: using imported CPVC polyethylene board, thickness of 8mm, one-button automatic open cover, with transparent observation window, combined with the defogging device, Convenient to observe the test, temperature resistance of about 120 degrees.
Water filling method	Automatic / manual dual water supply mode, automatic water inlet with a set of water purifier
specimen holder	● The inner wall of C PVC polyethylene dilute triangular tank box is used to place the dividing frame, the Angle of the test product can be adjusted at will, and the number of test pieces on all sides is completely consistent. ● The bottom of the test box. Uniuniform opening on the platform surface will discharge the spray liquid quickly, and large samples can be placed on the platform for testing.
refrigeration compressor	France taikang fully closed compressor
cooling medium	Non-fluorinated refrigerant R404A complies with environmental regulations, safe and non-toxic
Condenser mode	air-cooled
Safety protection device	refrigeration system	Compressor overheating protection Compressor overcurrent protection Over pressure and low pressure protection Condensate fan overheating protection
	test box	Adjustable overtemperature protection alarm Extreme overtemperature protection of the air conditioning channel Fan, motor superheater relay protection
	heating system	Heating pipe with dry burning protection Abnormal water supply alarm Abnormal drainage alarm
	other	earth leakage protection Overload and short-circuit protection The power supply lacks the reverse phase protection function
weight (Kg)	About 300	About 400	About 500	About 600	About 700
source	AC380V;50Hz;7KW	AC 380;V50Hz;9KW	AC 380;V50Hz;11KW	AC 380;V50Hz;13KW	AC 380;V50Hz;15KW



Refrigeration Compressor

The Salt Spray Test Chamber (New) is equipped with a fully closed compressor from France Taikang. This ensures efficient and reliable performance for accurate testing results.

Relative Humidity Fluctuation

With a fluctuation of only ±2% relative humidity, this chamber maintains consistent and precise testing conditions for reliable and accurate results.

Choose the Salt Spray Test Chamber (New) for your corrosion testing needs and experience the benefits of high precision, energy-saving design, and automatic control. Contact us today to learn more about our customizable design options.

Applications:

Salt Spray Test Chamber (New) - INFINITY

Brand Name: INFINITY

Model Number: IE 40 Series

Place of Origin: MADE IN CHINA

Certification: CE, ISO

Minimum Order Quantity: 1

Price: Negotiate

Packaging Details: Clear sheet+sponge+wood carton

Delivery Time: 20-30 days after order confirmed

Payment Terms: TT, PAYPAL, Moneygram and so on

Supply Ability: 200 sets / month

Humidity deviation: ±2%R.H

Temperature range: 0℃ ～ +90℃

Relative humidity fluctuation: ±2%R.H

Humidity uniformity: ±3%R.H

Temperature uniformity: ≦2.0℃

The Salt Spray Test Chamber (New) by INFINITY is a advanced and high-quality environmental salt spraying tester designed for testing the corrosion resistance of various materials. It is an essential equipment for industries such as electronics, automotive, aerospace, and metal coatings.

The Salt Spray Test Chamber is used in various scenarios where corrosion resistance of materials needs to be tested. Some of the common applications include:

• Research and Development laboratories
• Quality control departments
• Manufacturing plants
• Coating and plating industries
• Automotive and aerospace industries
• Electronics and electrical industries

• Salt mist spray test chamber
• Environmental salt spraying tester
• Salt spray testing machine
• Corrosion resistance testing equipment
• Advanced and precise temperature and humidity control
• High-quality materials for long-lasting performance
• User-friendly interface and easy operation
• Customizable test parameters and settings
• Excellent temperature and humidity uniformity
• Compact and space-saving design

• Temperature range: 0℃ ～ +90℃
• Humidity range: 30%RH ~ 98%RH
• Humidity deviation: ±2%R.H
• Relative humidity fluctuation: ±2%R.H
• Humidity uniformity: ±3%R.H
• Temperature uniformity: ≦2.0℃
• Material: SUS304 stainless steel
• Power supply: AC 220V 50Hz

INFINITY is a leading manufacturer and supplier of environmental testing equipment. Our Salt Spray Test Chamber is designed and produced with the latest technology and high-quality materials to ensure accurate and reliable test results. We also offer excellent after-sales service and technical support to our customers. With our commitment to quality and customer satisfaction, we have gained a good reputation in the industry.

Customization:

Packing and Shipping:

The salt spray test chamber (new) is carefully packaged before shipment. It is first wrapped in protective materials to prevent any damage during transportation. Then, it is placed in a sturdy wooden crate and secured with straps to ensure it stays in place.

We offer both sea and air freight options for shipping, depending on the customer's preference and location. For sea freight, the chamber is loaded onto a container and shipped to the nearest port. For air freight, the chamber is loaded onto a cargo plane and delivered to the nearest airport.

Once the chamber reaches its destination, our team will coordinate with the customer to ensure prompt delivery and installation. We also provide detailed instructions and support for setting up and operating the chamber.

With our careful packaging and efficient shipping methods, we guarantee that the salt spray test chamber (new) will arrive in perfect condition and ready for use.

FAQ:

• Q: What is the brand name of this product?
• A: The brand name of this product is INFINITY.
• Q: What is the model number of this product?
• A: The model number of this product is IE 40 Series.
• Q: Where is this product made?
• A: This product is made in China.
• Q: What certifications does this product have?
• A: This product is certified by CE and ISO.
• Q: What is the minimum order quantity for this product?
• A: The minimum order quantity for this product is 1 set.
• Q: Can the price of this product be negotiated?
• A: Yes, the price of this product is negotiable.
• Q: How is this product packaged?
• A: This product is packaged with clear sheet, sponge, and wood carton.
• Q: What is the delivery time for this product?
• A: The delivery time for this product is 20-30 days after order confirmed.
• Q: What payment terms are accepted for this product?
• A: This product can be paid for with TT, PayPal, Moneygram, and other methods.
• Q: How many sets of this product can be supplied per month?
• A: 200 sets of this product can be supplied per month.
