UL2468 PVC Flat Ribbon Cable AWG24 PH1.50 PH2.54 RoHS & Reach Compliant 80C 300V
Price:
0.12 per meter
MOQ:
610 meters
Delivery Time:
9 days for ready goods
Brand:
WCH Cable
Product Description
UL2468 PVC Flat Ribbon Cable AWG24 PH1.50 PH2.54 RoHS & Reach Compliant 80C 300V
Style Description: UL2468, Flat Cable, Flat Ribbon Cable, PVC Flat Cable
Rating: 80 deg C, 300 Vac, Horizontal flame. Optional - 60 or 80 deg C Oil.
Insulation Material: Extruded PVC.
Standard: Appliance Wiring Material UL 758.
Application: Internal wiring.
| Approval Style Number | Cores | Conductor | Number of Conductor | Pitch | Insulation Thickness | Overall Diameter | Conductor Resistance |
| NO | AWG | mm | mm | mm | Ω/KM | ||
| UL2468 | 2 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×3.00 | 94.20 |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×5.08 | 94.20 | ||
| 3 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×4.50 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×7.62 | 94.20 | ||
| 4 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×6.00 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×10.16 | 94.20 | ||
| 5 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×7.50 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×12.70 | 94.20 | ||
| 6 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×9.00 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×15.24 | 94.20 | ||
| 7 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×10.05 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×17.78 | 94.20 | ||
| 8 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×12.00 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×20.32 | 94.20 | ||
| 9 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×13.50 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×22.86 | 94.20 | ||
| 10 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×15.00 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×25.40 | 94.20 | ||
| 11 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×15.40 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.5×27.94 | 94.20 | ||
| 12 | 24 | 11/0.16 | 1.50 | 0.45 | 1.4×18.00 | 94.20 | |
| 24 | 7/0.20 | 2.54 | 0.45 | 1.4×30.48 | 94.20 | ||
| 13 | 24 | 7/0.20 | 1.50 | 0.45 | 1.5×19.50 | 94.20 | |
| 14 | 24 | 7/0.20 | 1.50 | 0.45 | 1.5×21.00 | 94.20 | |
| 15 | 24 | 7/0.20 | 1.50 | 0.45 | 1.5×19.50 | 94.20 |
