UL2468 PVC Flat Ribbon Cable AWG26 PH1.40 PH2.0 PH2.54 RoHS & Reach Compliant 80C 300V
Price:
0.12 per meter
MOQ:
610 meters
Delivery Time:
9 days for ready goods
Brand:
WCH Cable
Product Description
80C 300V PVC Flat Ribbon Cable UL2468 AWG26 PH1.40 PH2.0, PH2.54 RoHS & Reach Compliant
Style Description: UL2468, Flat Cable, Flat Ribbon Cable, PVC Flat Cable
Rating: 80 deg C, 300 Vac, Horizontal flame. Optional - 60 or 80 deg C Oil.
Insulation Material: Extruded PVC.
Standard: Appliance Wiring Material UL 758.
Application: Internal wiring.
| Approval Style Number | Cores | Conductor | Number of Conductor | Pitch | Insulation Thickness | Overall Diameter | Conductor Resistance |
| NO | AWG | mm | mm | mm | Ω/KM | ||
| UL2468 | 2 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×2.9 | 150.00 |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×3.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×3.9 | 150.00 | ||
| 3 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×4.4 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×5.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×6.4 | 150.00 | ||
| 4 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×5.9 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×7.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×8.9 | 150.00 | ||
| 5 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×7.4 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×9.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×11.4 | 150.00 | ||
| 6 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×8.9 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×11.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×13.9 | 150.00 | ||
| 7 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×10.4 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×13.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×16.4 | 150.00 | ||
| 8 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×11.9 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×15.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×18.9 | 150.00 | ||
| 9 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×13.4 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×17.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×21.4 | 150.00 | ||
| 10 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×14.9 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×19.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×23.9 | 150.00 | ||
| 11 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×16.4 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×21.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×26.4 | 150.00 | ||
| 12 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×17.9 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×23.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×28.9 | 150.00 | ||
| 13 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×19.4 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×25.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×31.4 | 150.00 | ||
| 14 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×20.9 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×27.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×33.9 | 150.00 | ||
| 15 | 26 | 7/0.16 | 1.40 | 0.45 | 1.4×22.4 | 150.00 | |
| 26 | 7/0.16 | 2.00 | 0.45 | 1.4×29.4 | 150.00 | ||
| 26 | 7/0.16 | 2.54 | 0.45 | 1.4×36.4 | 150.00 |
