UL21016 XLPE Flat Ribbon Cable Irradiated PE Pitch 2.0MM, 2.54MM 105C 300V
Price:
0.10 per meter
MOQ:
1220 meters
Delivery Time:
9 days for ready goods
Brand:
WCH Cable
Product Description
UL21016 XLPE Flat Ribbon Cable Irradiated PE Pitch 2.0MM, 2.54MM 105C 300V
Style Description: UL21016, Flat Cable, Flat Ribbon Cable, Irradiated Flat Cable
Rating: 105 deg C, 300 Vac, Horizontal flame.
Insulation: XLPE, 9 mils min average, 8 mils minimum at any point.
Standard: Appliance Wiring Material UL 758.
Application: Internal Wiring of Appliances.
WCH Cable - Professional Manufacturer of Ribbon Cable, UL Cord, Cable Assembly
| Style Number | Conductor Structure | Pitch Distance | Pin Quantity | Insulation Thickness | Overall Diameter | Conductor Resistance | |
| AWG | No./mm | mm | Pin | mm | mm | Ω/KM | |
| UL21016 | 26 | 7/0.16 | 2.54 | 2P-40P | 0.23 | 1.05 | 150 |
| 26 | 7/0.16 | 2.00 | 2P-50P | 0.23 | 1.05 | 150 | |
| 26 | 7/0.16 | 1.27 | 2P-50P | 0.23 | 1.05 | 150 | |
| 26 | 7/0.16 | 1.05 | 2P-50P | 0.23 | 1.05 | 150 | |
| UL21016 | 28 | 7/0.127 | 2.54 | 2P-50P | 0.23 | 0.90 | 239 |
| 28 | 7/0.127 | 2.00 | 2P-60P | 0.23 | 0.90 | 239 | |
| 28 | 7/0.127 | 1.27 | 2P-64P | 0.23 | 0.90 | 239 | |
| 28 | 7/0.127 | 1.00 | 2P-64P | 0.23 | 0.90 | 239 | |
| 28 | 7/0.127 | 0.90 | 2P-64P | 0.23 | 0.90 | 239 | |
Tag: UL21016, UL21016 XLPE cable, cable factory, flat ribbon cable
