UL20280 (24AWG) 8 Conductors Oil Resistant TPU Spiral Cable Black Jacket with Colorful PP Insulated Wire
Price:
USD 0.12 per piece
MOQ:
200 pcs per box
Delivery Time:
9 days for ready goods
Brand:
WCH Cable
Product Description
UL20280 (24AWG) 8 Conductors Oil Resistant TPU Spiral Cable Black Jacket with Colorful PP Insulated Wire
UL Style Description: UL20280 (24AWG) Oil Resistant TPU Spiral Cable
Rating: 80 deg C, 300 Vac, Horizontal flame
Conductor Size: 24AWG
Conductor Quantity: 2 ~ 50 cores
Insulation Material: Polypropylene PP
Jacket Material: Thermoplastic polyurethane TPU
Executed Standard: Appliance Wiring Material UL 758.
Application: Internal wiring or external interconnection of appliances or electronic equipment.
| Approval Style Number | Cores | Conductor | Insulation Thickness |
Nominal Diameter | Shield Coverage | Jacket Thickness | Overall Diameter |
Conductor Resistance |
|
| AWG | No/mm | mm | mm | % | mm | mm | Ω/KM | ||
| UL20280 (CUL) |
2C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 4.60 | 94.20 |
| 3C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 4.70 | 94.20 | |
| 4C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 5.00 | 94.20 | |
| 5C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 5.20 | 94.20 | |
| 6C | 24 | 11/0.16 | 0.23 | 1.10 | >=65 | 0.86 | 5.70 | 94.20 | |
Spec Download: UL20280, UL20280 specification
Tag: UL20280, spiral cable
