TPU Cable UL20549 16AWG 3Cores OD6.8mm Glossy Black
Price:
USD0.16 per meter
MOQ:
3050 meters
Delivery Time:
9 days for ready goods
Brand:
WCH Cable
Product Description
UL20549 - Most popular UL style of TPU jacketed cable, excellent resilience for Spiral cable
TPU Cable UL20549 has a rated temperature 80 deg C, and a rated voltage 300V. Its minimum conductor size can be 32AWG, with 2 to 80 cores twisted together, in the form of pair twisted or group twisted. Insulation could be any AWM complied material, with different insulation colours for wiring identification. TPU jacket wall thickness is as thin as 0.38mm for first level of small cable structure. It is to be adjusted as subject to the assemblied core size.
TPU Cable UL20549 16AWG 3Cores OD6.8mm Glossy Black
| Conductor | Specification | (AWG) | 16 |
| Section Area | (mm²) | 1.3069 | |
| Material | Tinned stranded copper | ||
| Configuration | (mm) | TS65/0.16±0.007 | |
| Insulation | Ave Thickness | (mm) | 0.34 |
| Min Thickness | (mm) | 0.27 | |
| Over Diameter | (mm) | 2.20±0.10 | |
| Material | PP (RoHS) | ||
| Colour | White, Black, Red | ||
| Jacket | Ave Thickness | (mm) | 1.03 |
| Min Thickness | (mm) | 0.82 | |
| Over Diameter | (mm) | 6.80±0.30 | |
| Material | Polyurethane TPU (RoHS) | ||
| Colour | Green | ||
| Electrical Capability |
Rated Temperature | (℃) | 80 |
| Rated Voltage | (V) | 300 | |
| Conductor Resistance | (Ω/KM 20℃) | 14.6 | |
| Insulation Resistance | (MΩ/KM 20℃) | 100 | |
| Approval | UL Style Number | 20549 | |
| CSA Grade | I/II A | ||
| Environmental Standard | Lead Free | ||
| RoHS & Reach Compliant |
Spec Download: UL20549, Data sheet, UL20549 data sheet
