600V UL Power Cord Cable SOOW 14AWG 3C ABC Conductors OD13.5mm CPE Rubber Black
Price:
USD0.2356
MOQ:
5000 meters
Delivery Time:
9 days for ready goods
Brand:
WCH Cable
Product Description
| Conductor | Specification | (AWG) | 14 |
| Section Area | (mm²) | 2.0775 | |
| Material | Bare Stranded Copper | ||
| Configuration | (mm) | AS41/0.254±0.008 | |
| Conductor Quantity | 3C | ||
| Insulation | Average Thickness | (mm) | 1.15 |
| Minimum Thickness | (mm) | 0.92 | |
| Over Diameter | (mm) | 4.30±0.15 | |
| Material | EPR Rubber (RoHS) | ||
| Colour | Black, White, Red | ||
| Jacket | Average Thickness | (mm) | 2.12 |
| Minimum Thickness | (mm) | 1.69 | |
| Overall Diameter | (mm) | 13.50±0.30 | |
| Material | CPE Rubber (RoHS) | ||
| Colour | Black | ||
| Electrical Capability |
Rated Temperature | (℃) | 75 |
| Rated Voltage | (V) | 600 | |
| Conductor Resistance | (Ω/KM 20℃) | 8.62 | |
| Insulation Resistance | (MΩ/KM 20℃) | >2.5 | |
| Flammability | Fire Retardance | VW-1 | |
| CUL FT1 | |||
| Approval | UL Style Number | SOOW | |
| Environmental Standard | Lead Free | ||
| RoHS & Reach Compliant |
Tag: power cable, power cord, soow, soow cable, cpe cable
