China Wholesale 40inch PP Melt Blown Water Filter Cartridge Spun PP Sediment Filter Cartridge for sale

Wholesale 40inch PP Melt Blown Water Filter Cartridge Spun PP Sediment Filter Cartridge

Price Negotiable
Price: negotiable
MOQ: 1000pcs
Delivery Time: 15-30days
Brand: dannovo
Product Description

40"5um PP Melt Blown Water Filter Cartridge Spun PP Sediment Filter Cartridge



PP melt blown filter cartridge (PPF) is made from polypropylene material. It can remove

suspendedsubstances, particles and rust effectively. This cartridge usually works as the

prefiltration to protectthe behind filtration for water treatment system. Special cartridges

can be customized.



Product introduction

PP filter is also called the PP meltblown filter, meltblown filter made of polypropylene superfine fiber tangles made of hot-melt, fiber randomly in space to form a three-dimensional porous structure, pore dimension filtrate flows along the gradient distribution in surface, deep, fine filter in one, can retain different size impurities. The filter accuracy range of 0.5 100 m, the flux is 1.5 times more than the same precision real peak filter, can be configured to cover different types of connectors to meet the various needs of engineering installation.



Detailed Introduction

Filter Media Polypropylene
Length 5",9.75"9.8",10",20",30",40",50" ,60"
Micron Rating 1, 5, 10, 20,30, 50, 75, 100 μm
Inside Diameter 0.8"(20mm), 0.9"(23mm), 1"(26mm),
1.1"(28mm), 1.2"(30mm), 1.3"(33mm), 1.4"(36mm)
Outside Diameter 2.36"(60mm),2.4"(61mm), 2.5"(63mm), 2.55"(65mm)
Core PP
Gasket/O-ring Silicone, EPDM, Viton,
End Cap Flat ,222 O-Ring,226 O-Ring,Fin



PP melt blown filter cartridge  parameters:



Name

40"5um pp melt blown filter cartridge in water filter
Length 40 inch =1016mm(1000mm)
Inner diameter 28mm(30mm)
Outer diameter 62mm
Weight 440g
Function pre-filter use in the filter hosings to remove sediment ,iron trust and hair.
Processing flow 1500/H
Replacement time 6 months
Maximum differential pressure 3 kg f/cm²

Maximum operating temperature



 5-80°c




Type
Melt-Blown Filter Cartridges
Filter Media
Polypropylene
Nominal Length
10'',20'',30'',40''
Micron Rating
1, 5, 10, 25, 50, 75, 100 μm
End Cap
DOE, 2-222 Flat, 2-222 Fin, 2-226 Flat, 2-226 Fin
Operating Conditions
△P : 3.0 bar at 25℃, 2.0 bar at 40℃, 1.0 bar at 60℃
Applications
Plating Solutions, Pre RO/DI, Chemicals, Petrochemical Process, Food & Beverage, Electronics
————— Feature —————
pp melt blwon filter cartridg shows:



we are the factory of water fitler cartridge ,so we can supply you with all kinds of water filters with all kinds of requirements ,if you are interested ,please do not hesitate to contact me.
