DC DYNAMO SALOON CAR SMALL SIZE 70V 150A SELF-EXCITING TRAILER ALTERNATOR
VAN UPFIT AFTERMARKET SMALL SIZE 70V 150A SELF-EXCITING LIMOUSINE ALTERNATOR
Recreational vehicle become very popular among the young people.
The big power alternator and small size alternator is greatly demanded with the increasing power requirements.
| Description | Parameter |
| rotation | clockwise (viewed from the driving end) |
| working temperature | -40 ℃～110℃ |
| rated rotation speed | 6000rpm, |
| Max. working rotation speed | 9000rpm |
| unloaded speed | n≤1950rpm n=6000rpm, I=150A, U≥70V |
| voltage adjusting valve | n=6000rpm, T=25℃, I=5A, U=70±0.8V |
| temperature compensation ratio | -4mV～-7mV/℃ |
| rectifier structure | 11 tubes |
Specification:
1. rotation: clockwise (viewed
from the driving end)
2. working temperature: -40 ℃～110℃
3. rated rotation speed: 6000rpm,
Max. working rotation speed: 9000rpm
4. no load speed: n≤1950rpm
n=6000rpm, I=150A, U≥70V
voltage adjusting valve: n=6000rpm, T=25℃, I=5A, U=70±0.8V, temperature compensation ratio: -4mV～-7mV/℃.
Features:
1. 2 years warranty period.
2. more than 80% conversion efficency to save fuel.
3. good output under the ideal speed and low speed.
4. self excitation system is designed to the generator, thereby can connected with air conditioner directly.
5. multi tube rectifier structure.
