20 Inch 500mm Diamond Concrete Saw Blade 50mm Arbor for 50 MPA Hard Reinforced Concrete
50MPA Diamond Products Concrete Saw 50mm Center Hole
1. Description
This is the high grade laser welded diamond blade for cutting reinforced concrete we well export to EU markets, fast cutting and long life for cutting very hard reinforced concrete with 50 MPA! If you are looking for a high quality diamond blades with reasonable price, we are your best choice.
2. Specification
Diameter:500mm
Segment thickness:4.0mm
Segment height:12mm
Inner hole:25.4mm, 50mm as your request
| Inch | Diameter (mm) |
Teeth length (mm) |
Teeth thickness (mm) |
Teeth height (mm) |
Teeth number (nos) |
| 20" | 500 | 40 | 4.0 | 12 | 36 |
Other size Concrete Saw Blade we could do as following
| Inch | Diameter (mm) |
Teeth length (mm) |
Teeth thickness |
Teeth height (mm) |
Teeth number (nos) |
| 4" | 105 | 32 | 2.2 | 7/10/12 | 8 |
| 4.5" | 115 | 31 | 2.2 | 7/10/12 | 9 |
| 5" | 125 | 31 | 2.2 | 7/10/12 | 10 |
| 6" | 150 | 34 | 2.2 | 7/10/12 | 11 |
| 7" | 180 | 34 | 2.4 | 7/10/12 | 14 |
| 8" | 200 | 40 | 2.4 | 7/10/12 | 13 |
| 9" | 230 | 37 | 2.6 | 7/10/12 | 16 |
| 10" | 250 | 40 | 2.6 | 10/12/15 | 16 |
| 12" | 300 | 40 | 3.0 | 10/12/15 | 20 |
| 14" | 350 | 40 | 3.2 | 10/12/15 | 24 |
| 16" | 400 | 40 | 3.4 | 10/12/15 | 28 |
| 18" | 450 | 40 | 3.6 | 10/12/15 | 32 |
| 24" | 600 | 40 | 4.4 | 10/12/15 | 42 |
| 26" | 650 | 40 | 4.4 | 10/12/15 | 42 |
| 28" | 700 | 40 | 5.0 | 10/12/15 | 40 |
3.Feature
1)Soft Bond segment designed for cutting extra hard reinforced concrete.
2)Turbo segment allows quick remove mortar and better cooling result.
3)12mm segment height for a longer life, can also do 15mm according your request.
4)Silent core, cooling holes, special size and type segment, arbor hole is available .
