GE1209 CARD MT4400AC MT5500 MT3600 MT3700 MT3300 TEREX UNIT RIG BUCYRUS NTE240 NTE260 WHEEL MOTOR DRIVE GE
Price:
1-100 USD
MOQ:
1 PC
Delivery Time:
3-5 WORKING DAYS
Brand:
KOMATSU FITS
Product Description
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| STEERING CYLINDER AND BEARINGS | ||||
| Item | Part No | Description | Qty | |
| 0 | EL7952 | STEERING CYLINDER | 1 | |
| 1 | PC0585 | PISTON SEAL ASSEMBLY(1) | ||
| 2 | EL7953 | ROD | 1 | |
| 3 | PB9518 | BEARING (1) | ||
| 4 | VL7694 | LOCKNUT,NYLON-13/4"(1) | ||
| 5 | VL7699 | BEARING(1) | ||
| 6 | EH5932 | PISTON | ||
| 7 | EH5933 | HOUSING | ||
| 8 | SL8048 | SEAL,O-RING(1) | ||
| 9 | WA1433 | RING,BACKUP(1) | 1 | |
| 10 | EC4589 | GLAND | 1 | |
| 11 | TD8516 | CAPSCREW-3/4"-10NC×31/4" | 2 | |
| 12 | PC0557 | SEAL,ROD | 1 | |
| 13 | PB8937 | WIPER,ROD | 1 | |
| 14 | TD7882 | CAPSCREW-3/4"-10NC×13/4" | 4 | |
| 15 | C1602 | CAPSCREW-3/8"-16NCX1" | 6 | |
| 16 | PC1682 | BEARING,SPHERICAL | 2 | |
| 17 | EK3384 | RETAINER,ANTI-ROTATION | 2 | |
| 18 | C0312 | LOCKWASHER-3/8" | 1 | |
| 19 | VM0313 | PLUG (2) | 61 | |
| NS | AK4370 | NOTE:(1)INCLUDED INAK4370 SEAL KIT. | ||
| NS | (2)LOCATION IS DEPENDENT ON SIDE OF MACHINE | |||
| NS | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) | |||
| STEERING CYLINDER INSTALLATION | ||||
| Item | Part No | Description | Qty | Ref |
| 1 | PC2771 | CAPSCREW-1"-8NCX91/2" | 4 | |
| 2 | EF7971 | PIN | 4 | |
| 3 | EK3377 | SEAL,BEARING | 8 | |
| 4 | EK3376 | SPACER | 8 | |
| 5 | PC1682 | BEARING,SPHERICAL | 4 | |
| 6 | EL7952 | STEERING CYLINDER(SEE FIG 41812) | 2 | 41812 |
| 7 | EK3384 | RETAINER,ANTI-ROTATION | 4 | |
| 8 | C1602 | CAPSCREW-3/8"-16NCX1" | 32 | |
| 9 | C0312 | LOCKWASHER-3/8" | 32 | |
| 10 | EF7970 | WASHER | 4 | |
| 11 | EG1853 | RETAINER | 4 | |
| 12 | VH8186 | LOCKNUT-1"-8NC | 4 | |
| CAB GROUP | ||||
| INNER DOOR PANEL-LH 58E-54-10120 | ||||
| Item | Part No | Description | Qty | |
| 1 | SM3010 | HARNESS,POWER WINDOW | 1 | |
| 2 | SL9490 | GROMMET,RUBBER | 1 | |
| 3 | PC3276 | WINDOW REGULATOR AND MOTOR-LH | ||
| 4 | SM5390 | INSULATION,PANEL-LH | ||
| 5 | EL1022 | CAPSCREW-DRILLED | ||
| 6 | SM2165 | BRACKET,DOOR STRAP | ||
| 7 | EM7551 | STRAP,DOOR CHECK | ||
| 8 | SM2322 | CLIP,HAIR PIN | ||
| 9 | WB3560 | CAPSCREW-M8×1.25×12 | 2 | |
| 10 | SM2294 | COVER,INNER ACCESS | 1 | |
| 11 | WB3559 | CAPSCREW-M6×1.00×12 | 8 | |
| 12 | SM0926 | SCREW-M6×1.00 | 4 | |
| 13 | SM2738 | PANEL,INNER-LH | 1 | |
