915231 FAN GE UNIT RIG CAT NHL TEREX MT4400AC KOMATSU 730E 830E 930E MINING HAULER DUMP TRUCK WHEEL MOTOR DRIVE GE
Price:
1-100 USD
MOQ:
1 PC
Delivery Time:
3-5 WORKING DAYS
Brand:
CAT FITS
Product Description
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| FUEL TANK INSTALLATION | ||||
| Item | Part No | Description | Qty | Ref |
| 1 | 58E-04-00061 | FUEL TANK ASSEMBLY(SEE FIG 43531) | 1 | 43531 |
| 2 | C1669 | CAPSCREW-1"-8NCX31/2" | 4 | |
| 3 | WA4733 | FLAT WASHER-1" | 4 | |
| 4 | TY4907 | CAP | 2 | |
| 5 | PC0780 | MOUNT,RUBBER-TWO PIECE | 4 | |
| 6 | ED9895 | FLAT WASHER | 4 | |
| 7 | MM0708 | FLAT WASHER-M24 | 4 | |
| 8 | MM0476 | LOCKWASHER-M24 | 4 | |
| 9 | MM0163 | CAPSCREW-M24×3.00×160 | 4 | |
| ALTERNATOR WIRING 3/3 | ||||
| Item | Part No | Description | Qty | |
| 1 | CH4915 | CABLE(74D) | 1 | |
| 2 | CH4914 | CABLE(71J) | 1 | |
| 3 | TC1233 | NUT-3/8"-16NC | 2 | |
| 4 | TC1231 | LOCKWASHER-3/8" | 2 | |
| 5 | TR4436 | FLAT WASHER-3/8" | 2 | |
| 6 | WB1302 | CLAMP,CUSHION-5/16" | 2 | |
| 7 | MM0178 | NUT-M10×1.50 | 2 | |
| 8 | MM0471 | LOCKWASHER-M10 | 2 | |
| 9 | MM0461 | FLAT WASHER-M10 | 2 | |
| 10 | WB1303 | CLAMP,CUSHIONED-3/4" | 1 | |
| 11 | TY8375 | SPACER | 1 | |
| ALTERNATOR WIRING 2/3 | ||||
| ltem | Part No | Description | Qty | |
| 1 | EK4014 | THREADED STUD-M16×2.00X 305 | 1 | |
| 2 | MM0464 | FLAT WASHER-M16 | 3 | |
| 3 | MM0181 | NUT-M16×2.00 | 3 | |
| 4 | MM0474 | LOCKWASHER-M16 | 3 | |
| 5 | EC1090 | THREADED STUD-M16×2.00×184 | 2 | |
| 6 | EL3705 | BRACKET | 1 | |
| 7 | VC1387 | CAPSCREW-1/2"-13NCX1" | 2 | |
| 8 | TR5445 | LOCKWASHER-1/2" | 2 | |
| 9 | VC7836 | FLAT WASHER-1/2" | 2 | |
| 10 | XB1109 | CLAMP,UHMW | 4 | |
| 11 | VA0609 | SPACER | 2 | |
| 12 | ED8936 | CLEAT,CABLE | 6 | |
| 13 | TN2590 | SPACER,HOSE | 6 | |
| 14 | VN6187 | STUD-5/8"-11NC×5" | 1 | |
| 15 | TR9082 | FLAT WASHER-5/8" | ||
| 16 | VC1390 | LOCKWASHER-5/8" | ||
| 17 | TV1749 | NUT-5/8"-11NC | 1 | |
| ALTERNATOR WIRING 1/3 | ||||
| Item | Part No | Description | Qty | |
| 1 | TR9082 | FLAT WASHER-5/8" | 3 | |
| 2 | VC1390 | LOCKWASHER-5/8" | 3 | |
| 3 | TV1749 | NUT-5/8"-11NC | 3 | |
| 4 | VN6187 | STUD-5/8"-11NC×5" | 3 | |
| 5 | EM8107 | O-RING,METAL CLAD | 6 | |
| 6 | MM0181 | NUT-M16×2.00 | 8 | |
| 7 | MM0474 | LOCKWASHER-M16 | 8 | |
| 8 | MM0464 | FLAT WASHER-M16 | 8 | |
| 9 | EB9886 | THREADED STUD-M16×2.00×127 | 4 | |
| 10 | XB1109 | CLAMP,UHMW | 6 | |
| 11 | VA0609 | SPACER | 10 | |
| 12 | ED8936 | CLEAT,CABLE | 28 | |
| 13 | TN2590 | SPACER,HOSE | 24 | |
| 14 | EK4014 | THREADED STUD-M16×2.00×305 | 2 | |
| WHEEL MOTOR WIRING 4/4 | ||||
| Item | Par No | Description | Qty | |
| 1 | VC8762 | CAPSCREW-3/8"-16NC×11/2" | 24 | |
| 2 | TR4436 | FLAT WASHER-3/8" | 24 | |
| 3 | TC1231 | LOCKWASHER-3/8" | 24 | |
| 4 | TC1233 | NUT-3/8"-16NC | 24 | |
| 5 | EK9880 | BUS BAR | 6 | |
| 6 | XB0498 | NIPPLE | 12 | |
| 7 | XB7780 | CLAMP,UHMW | 24 | |
| 8 | MM0474 | LOCKWASHER-M16 | 18 | |
| 9 | EC1090 | THREADED STUD-M16×2.00×184 | 12 | |
| 10 | MM0464 | FLAT WASHER-M16 | 12 | |
| 11 | MM0181 | NUT-M16×2.00 | 12 | |
| NS | NOTE:NS=NOT SHOWN | |||
| NS | PC0284 | BOOT,SHRINK | 9 | |
| NS | WA1578 | TAPE,FILLER(152 CM) | 6 | |
| WHEEL MOTOR WIRING % | ||||
| Item | Part No | Description | Qty | |
| 1 | EC1090 | THREADED STUD-M16×2.00×184 | 6 | |
| 2 | MM0464 | FLAT WASHER-M16 | 6 | |
| 3 | MM0696 | LOCKNUT-M16×2.00 | 6 | |
| 4 | XB7780 | CLAMP,UHMW | 12 | |
| 5 | MM0474 | LOCKWASHER-M16 | 6 | |
| 6 | EL3879 | BRACKET | 1 | |
| 7 | MM0010 | CAPSCREW-M12×1.75X25 | 2 | |
| 8 | MM0472 | LOCKWASHER-M12 | 2 | |
| 9 | MM0462 | FLAT WASHER-M12 | 2 | |
| 10 | EL2834 | PLATE | 1 | |
| 11 | MM0031 | CAPSCREW-M20×2.50×45 | 2 | |
| 12 | MM0475 | LOCKWASHER-M20 | 2 | |
| 13 | MM0465 | FLAT WASHER-M20 | 2 | |
| 14 | EL2833 | GASKET | ||
| 15 | CH3691 | CABLE(7M1C1) | ||
| 16 | CH3680 | CABLE(7M1C2) | ||
| 17 | CH3690 | CABLE(7M1B2) | ||
| 18 | CH3677 | CABLE(7M1B1) | ||
| 19 | CH3689 | CABLE(7M1A1) | ||
| 20 | CH3676 | CABLE(7M1A2) | ||
