15232707 MAINFOLD HOIST KOMATSU 730E 830E 930E 960E MINING DUMP TRUCK WHEEL MOTOR DRIVE GE
Price:
1-100 USD
MOQ:
1 PC
Delivery Time:
3-5 WORKING DAYS
Brand:
FITS KOMATSU GE UNIT RIG TEREX
Product Description
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| Komatsu 730E | |||
| Item | PN# | Description | QTY |
| 1 | motorized wheel | 1 | |
| 2 | BF3897 | frame structure assembly | 1 |
| 3 | VE8235 | gear and piston | 3 |
| 4 | VE8232 | torque tube | 1 |
| 5 | BF1484 | capscrew | 44 |
| 6 | VE3922 | washer | 44 |
| 7 | VE4785 | ring,adapter | 1 |
| 8 | BF2111 | motor | 1 |
| 9 | VE0654 | bearing | 3 |
| 10 | VE4495 | bearing cap | 3 |
| 11 | VE0653 | bearing | 3 |
| 12 | VE5185 | flat washer | 40 |
| 13 | C1620 | capscrew | 16 |
| 14 | VE4496 | nut | 3 |
| 15 | VE4497 | lockwasher | 3 |
| 16 | VE0500 | bearing,inboard | 1 |
| 17 | VE4742 | hub,wheel | 1 |
| 18 | VE4744 | seal ring | 1 |
| 19 | VE0662 | wear band | 3 |
| 20 | VE0656 | wear band | 1 |
| 21 | VE0518 | oil seal | 1 |
| 22 | VE7201 | O'ring | 1 |
| 23 | VE0655 | packing | 1 |
| 24 | TD8074 | cement | 1 |
| 25 | VE0763 | seal ring | 1 |
| 26 | C5768 | plug,pipe | 16 |
| 27 | VE4508 | flinger | 1 |
| 28 | VE4489 | screw | 36 |
| 29 | VS8999 | seal | ar |
| 30 | VE4243 | washer,concave | 144 |
| 31 | VE4403 | clamp | 36 |
| 32 | VJ9656 | sealer | 1 |
| 33 | VE0760 | seal housing | 1 |
| 34 | BF0279 | capscrew | 18 |
| 35 | BF3896 | wire | 1 |
| 36 | BF3900 | capscrew | 6 |
| 37 | VE2971 | planet cover | 1 |
| 38 | VS9430 | capscrew | 52 |
| 39 | VE0517 | seal | 2 |
| 40 | VE0756 | ring | 1 |
| 41 | BF1486 | capscrew | 18 |
| 42 | VE8234 | collar | 3 |
| 43 | VE8699 | bearing cap | 3 |
| 44 | VE4752 | ring | 3 |
| 45 | VE8691 | sleeve | 3 |
| 46 | VE1273 | seal ring | 1 |
| 47 | VJ2672 | cement | 1 |
| 48 | VE2974 | pinion&shaft | 1 |
| 49 | VE0665 | sun pinion cover | 1 |
| 50 | VS8411 | plug magnetic | 1 |
| 51 | VS9430 | capscrew | 6 |
| 52 | VS8410 | gasket | 1 |
| 53 | VE4548 | ring | 1 |
| 54 | VE4782 | compound | ar |
| 55 | BF3863 | capscrew | 1 |
| 56 | VE5185 | flat washer | 1 |
| 57 | VE4739 | capscrew | 4 |
| 58 | VE4687 | Lockwasher | 4 |
| 59 | VE4783 | putty,silastic | 1 |
| 60 | VE4470 | insulation | 1 |
| 61 | VE4335 | tape fiberglass | 1 |
| 62 | VE3915 | varnish | 1 |
| 63 | XA3628 | air deflector | 8 |
| 64 | VE5188 | flat washer | 24 |
| 65 | VE4745 | screw | 24 |
| 66 | VE4743 | plug,pipe | 6 |
| 67 | VE4234 | Bearing cap | 1 |
| 68 | VE4746 | seal ring | 1 |
| 69 | VE4500 | capscrew | 12 |
| 70 | VE3027 | washer | 30 |
| 71 | VE2466 | thrust ring | 1 |
| 72 | VE0663 | shim set | 1 |
| 73 | VE4501 | shim | 20 |
| 74 | VE4502 | shim | 16 |
| 75 | VE4503 | shim | 20 |
| 76 | VE4504 | shim | 5 |
| 77 | VE4505 | shim | 4 |
| 78 | shim | 5 | |
| 79 | VE0517 | seal | 1 |
| 80 | VE0667 | capscrew | 9 |
| 81 | VE4696 | Lockwasher | 4 |
| 82 | VS8330 | screw | 4 |
| 83 | VE4784 | washer | 10 |
| 84 | VE4473 | Bolt | 1 |
| 85 | PB8889 | brake hub | 1 |
| 86 | VE0755 | end plate | 1 |
| 87 | VE4361 | cable tie | ar |
| 88 | VE0499 | Bearing,outboard | 1 |
| 89 | VE4499 | capscrew | 10 |
| 90 | VJ0972 | Magnetic pickup | 1 |
| 91 | VE0662 | wear band | 3 |
| 92 | AK3653 | Brush carbon | 12 |
| 93 | VE0757 | Armature | 1 |
| 94 | VE8236 | Armature head | 1 |
| 95 | VE6097 | end punching | 1 |
| 96 | VE6101 | kit rewind | 1 |
| 97 | VE6819 | Wire | 1 |
| 98 | VE0749 | balance weight | 1 |
| 99 | VE7211 | bearing housing | 1 |
| 100 | VE0636 | bearing | 1 |
| 101 | VE4536 | collar | 1 |
| 102 | VE7212 | V-ring seal | 1 |
| 103 | VE4518 | capscrew | 4 |
| 104 | VE5185 | flat washer | 4 |
| 105 | BF1660 | seal teflon | 1 |
| 106 | BF2112 | bearing cap | 1 |
| 107 | VE6099 | punching,step back | 1 |
| 108 | VE7207 | collar | 1 |
| 109 | VE7206 | tape,glass | 1 |
| 110 | VE8701 | band,teflon | 1 |
| 111 | VE5046 | Tape,glass | 1 |
| 112 | VE0748 | Balance weight | 1 |
| 113 | VE3002 | collar | 1 |
| 114 | BF3418 | Bearing ball | 1 |
| 115 | VE1892 | Bearing cap | 1 |
| 116 | VE0752 | spacer | 1 |
| 117 | VE1893 | gear | 1 |
| 118 | PB0101 | magnetic pickup | 1 |
| 119 | VE0751 | felt packing | 1 |
| 120 | WA0471 | capscrew | 8 |
| 121 | VE5185 | flat washer | 8 |
| 122 | VE4758 | head,frame | 1 |
| 123 | VE4776 | capscrew | 10 |
| 124 | VE5184 | flat washer | 10 |
| 125 | VE4780 | air baffle | 1 |
| 126 | VE4781 | air baffle W/CO | 1 |
| 127 | TC1234 | capscrew | 4 |
| 128 | VE4687 | Lockwasher | 4 |
| 129 | VE0758 | air baffle | 2 |
| 130 | VN9021 | capscrew | 6 |
| 131 | VE4490 | washer | 6 |
| 132 | VE8237 | punching,end | 1 |
| 133 | VE6100 | Commutator,season | 1 |
| 134 | BF3897 | frame structure assembly | 1 |
| 135 | VE4733 | line with fittings | 1 |
| 136 | VE4477 | nut | 2 |
| 137 | VE4478 | sleeve | 2 |
| 138 | VE4734 | line with fittings | 1 |
| 139 | VE4735 | line with fittings | 1 |
| 140 | VE4736 | line with fittings | 1 |
| 141 | BF3898 | hose | 1 |
| 142 | BF3899 | hose | 2 |
| 143 | BF3861 | hose clamp | 6 |
| 144 | VE2836 | cable&clamp | 2 |
| 145 | VE4483 | clamp | 1 |
| 146 | VE3957 | cable | 1 |
| 147 | VE3179 | cleat | 2 |
| 148 | VE3180 | clamp | 2 |
| 149 | VE3181 | bracket | 2 |
| 150 | VE4487 | strap | 2 |
| 151 | VJ1024 | clamp | 1 |
| 152 | VE4488 | sleeve | 4 |
| 153 | VE4489 | screw | 2 |
| 154 | VE4490 | washer | 2 |
| 155 | VE4491 | strap | 2 |
| 156 | VE4492 | insulation | 1 |
| 157 | VE4739 | capscrew | 4 |
| 158 | VE4229 | cable assembly | 1 |
| 159 | VE4484 | Pad | 1 |
| 160 | VE6088 | tubing | 2 |
| 161 | VE3919 | spacer | 1 |
| 162 | BF2610 | cable/connection | 3 |
| 163 | VJ6489 | plug | 2 |
| 164 | VS8047 | Pipe plug | 1 |
| 165 | VS8411 | plug magnetic | 1 |
| 166 | BF5149 | pipe cap | 1 |
| 167 | VE8378 | cap,oil | 1 |
| 168 | VE1000 | gasket,oil cap | 1 |
| 169 | VS8408 | Pin | 1 |
| 170 | VE1272 | terminal block | 2 |
| 171 | TV1918 | capscrew | 4 |
| 172 | VE4490 | flat washer | 8 |
| 173 | TV6025 | capscrew | 7 |
| 174 | VJ3550 | flat washer | 7 |
| 175 | SP8417 | flat washer | 7 |
| 176 | VE2308 | nut | 14 |
| 177 | VE7202 | flat washer | 14 |
| 178 | VJ0969 | strap | 6 |
| 179 | VE4750 | insulator | 12 |
| 180 | TC1233 | Nut | 12 |
| 181 | VE4515 | flat washer | 12 |
| 182 | VE4739 | capscrew | 4 |
| 183 | VE4516 | washer | 8 |
| 184 | VE3917 | Nut | 4 |
| 185 | VE4519 | washer | 2 |
| 186 | VE4520 | Nut,hex jam | 2 |
| 187 | VE4699 | Lockwasher | 2 |
| 188 | VE4524 | jumper | 1 |
| 189 | VE4752 | cement | 1 |
| 190 | VE8232 | tube,torque | 1 |
| 191 | VE4537 | support | 2 |
| 192 | VJ0936 | dowel | 2 |
| 193 | VE0935 | dowel pin | 2 |
| 194 | TH7541 | capscrew | 8 |
| 195 | VE5188 | flat washer | 8 |
| 196 | VJ4091 | cement | 1 |
| 197 | VE0638 | coil-exc pole | 4 |
| 198 | VE4761 | coil with pole piece | 3 |
| 199 | VE4762 | coil with pole piece | 1 |
| 200 | VE4767 | connection strap | 1 |
| 201 | VE4768 | connection strap | 1 |
| 202 | VE4769 | connection strap | 2 |
| 203 | VE4770 | connection strap | 1 |
| 204 | VE4771 | connection strap | 1 |
| 205 | VE0640 | capscrew | 12 |
| 206 | VE0641 | capscrew | 12 |
| 207 | VE1481 | cable assembly | 1 |
| 208 | VE1482 | cable assembly | 2 |
| 209 | VE1483 | cable assembly | 1 |
| 210 | VE4473 | cable assembly | 1 |
| 211 | VE4541 | brazing strip | 16 |
| 212 | VE4783 | silastic putty | 1 |
| 213 | VE7214 | tape silicone | 1 |
| 214 | VE4775 | tape fiberglass | 1 |
| 215 | VE3915 | varnish | 1 |
| 216 | VE4552 | capscrew | 8 |
| 217 | VE4543 | washer | 8 |
| 218 | VE4778 | air deflector | 8 |
| 219 | VE4542 | capscrew | 16 |
| 220 | VE4699 | Lockwasher | 16 |
| 221 | VE4490 | washer | 16 |
| 222 | VE4361 | cable tie | 4 |
| 223 | VJ0928 | support | 4 |
| 224 | VF7377 | capscrew | 4 |
| 225 | VE7610 | flat washer | 4 |
| 226 | VE4772 | cable assembly | 1 |
| 227 | VE4492 | insulator | 1 |
| 228 | VE8429 | brush holder assembly | 4 |
| 229 | VE8428 | brush lever assembly | 12 |
| 230 | VJ0916 | bushing | 12 |
| 231 | VJ0917 | hinge pin | 4 |
| 232 | SG3468 | roll pin | 8 |
| 233 | VJ0918 | roll pin | 8 |
| 234 | VE7213 | bolt and washer | 8 |
| 235 | VJ0920 | bushing | 16 |
| 236 | VE4264 | spring set assembly | 12 |
| 237 | VJ0926 | hinge pin | 4 |
| 238 | VJ6458 | teflon sleeve | 8 |
| 239 | VR3001 | stud | 8 |
| 240 | VE4764 | stud | 8 |
| 241 | VE6103 | seat spring | 12 |
| 242 | VE6104 | seat spring with pin | 12 |
| PB6463 |
| PB6331 |
| PB6332 |
| VE1894 |
| VE6951 |
| PB6464 |
| BF4581 |
| PB9492 |
| PC0395 |
| PC0395 |
| PB9493 |
| PB9493 |
| PB9494 |
| EJ2073 |
| XA2700 |
| EJ2074 |
| XA2701 |
| EJ2075 |
| XA2734 |
| PB9496 |
| XA2896 |
| XA4917 |
| XA5826 |
| XA5923 |
| GE0026 |
| GE1174 |
| GE0850 |
| 58F-06-00250 |
| XA2476 |
| XA2476 |
| GE0851 |
| GE0851 |
| 58F-06-00410 |
| GE0852 |
| GE0852 |
| 58F-06-00420 |
| XA2475 |
| XA2475 |
| GE0853 |
| GE1253 |
| GE1253 |
| 58E-06-00850 |
| GE0025 |
| XA5829 |
| XA3146 |
| 58E-06-00860 |
| GE0435 |
| XA5825 |
| GE0022 |
| XA5828 |
| GE1300 |
| XA3147 |
| XA3147 |
| 58E-06-00870 |
| XA3148 |
| XA5827 |
| 58B-06-00230 |
| XA5864 |
| 58B-06-00210 |
| XA5862 |
| XA5859 |
| XA5857 |
| XA5858 |
| XA5860 |
| 58B-06-00220 |
| XA5863 |
| BF3902 |
| TA9428 |
| PB0807 |
| 58E-06-01212 |
| 58F-06-04460 |
| 58B-06-01920 |
| 58F-06-01660 |
| 58F-06-04480 |
| 58F-06-01640 |
| 58F-06-01650 |
| 58F-06-04450 |
| 58E-06-03850 |
| 58E-06-00941 |
| 58E-06-00951 |
| 58E-06-00991 |
| 58E-06-01221 |
| 58E-06-00962 |
| 58E-06-00972 |
