NEW SGM7G-13A7C61
Yaskawa Servo Motor SGM7G-13A7C61 or SGM7G13A7C61 New
Overview:
24-bit high-resolution encoder installed
High efficiency, low heat generation
Downsizing by up to 20%
Flange compatible with Sigma-5
Medium inertia, low speed, high torque
| Parameter | Specification |
|---|---|
| Input Power Supply | 200 V |
| Rated Output | 1.3 kW |
| Shaft End | Straight with key and tap |
| Encoder Resolution | 24 bit |
| Encoder Type | Absolute |
| Options | Without options |
| Height | 169 mm |
| Width | 130 mm |
| Depth | 211 mm |
| Weight | 7.1 kg |
| Allowable Load Moment of Inertia | 5 Times |
| Rated Torque | 8.34 Nm |
| Instantaneous Maximum Torque | 23.3 Nm |
| Rated Motor Speed | 1500 1/min |
| Maximum Motor Speed | 3000 1/min |
| Motor Moment of Inertia | 19.9 × 10⁻⁴ kg·m² |
| Flange Dimension (LC) | 130 mm |
| Flange Diameter (LA) | 145 mm |
| Shaft End Diameter (S) | 24 mm |
| Shaft End Length (Q) | 40 m |
