Paddle Agitator Chemical Mixing Machine With Turnover Mixing Tank 600L
600L Horizontal Chemical Powder Mixing Machine With Turnover Mixing Tank
Features:
Production rate: 300kg/hour(Mainly used in wet material or paste material,especially suitable for food and pharmaceutical industry).
Spindle speed: 20 revolutions per minute.
Main motor power: 5.5 KW
Power source: 380V /50Hz
Mixing period: 30minutes
Angle of inclination:105°
Overal size: (LxWxH) 2400x800x1650 mm
It features high mixing precision, and widely applicable to food, chemical industries.Vessel, blending parts, drive unit, feeding and discharging comprise the main body. It achieves good mixing effect for the mixture even with liquid additives less than 15%. Different discharging systems are optional.
Technical Parameter:
| Model | QZ-W300 |
| Mixing Capacity | 300KG 600L 0.6CBM |
| Power | 5.5KW-4 |
| Dimension | L2400xW800xH1650 mm |
| Material of Mixing Tank | 304SS |
| Overturn Mixing Tank | Yes |
| Loading Material | Manual |
