5.5kw 24mm Hollow Shaft Motor with Aluminum Alloy Housing for Washing Machine and Industrial Applications
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
ZOZHI
Product Description
112M Hollow Shaft Washing Machine Motor
24MM hollow shaft electric motors 112M 5.5kw
Product Overview
The Hollow Shaft Motor is an ideal choice for high-pressure pumps, pressure washing machines and other industrial applications. Featuring a lightweight aluminum alloy housing, this three-phase asynchronous motor offers reliable performance with a rated power of 0.55KW and a rated torque of 2.2N.m. Its FAN cooling method ensures maximum safety and efficiency, and its weight of only 2.5kg makes it easy to install and transport.
Key Features
- Product Name: Hollow Shaft Motor
- Rated Power: 5.5KW
- Rated Torque: 2.2N.m
- Housing Material: Aluminum Alloy
- Insulation Class: F
- Weight: 30kg
- Application: Ideal for three phase asynchronous motor, high pressure pump and pressure washing machine.
![]()
Applications
The direct coupling between the motor and high-pressure pump, ideal for pressure cleaners and washing plants, significantly reduces the machine's overall size and provides a reliable and cost-efficient solution. We have a wide range of flanges and shafts suitable for direct coupling with most of the pumps on the market today.
Product Advantages
- High-Efficiency Motor: High-standard material with 100% output
- Popular Motor: Get good feedback from customer
- OEM & ODM: Customized service
- Direct Manufacturer: 24 hours online service
- 3 Years Warranty: Almost without any after service
- 7 Days Shipment: Stock Material
Related Products
Hollow Shaft Motor Three Phase Motor
Hollow Shaft Motor Single Phase Motor
Solid Shaft Motor 3 Phase Motor
Solid Shaft Motor Mono phase Motor
Solid Shaft Motor AC induction single-phase motor
Electric Centrifugal Switch For Single Phase Motor
Factory Overview
Customer Feedback
Technical Specifications
Three-Phase Hollow Shaft Motor 400V 50Hz (IE1/IE2/IE3)
| FRAME | POWER | RPM | COS φ |
|---|---|---|---|
| HS90L1-2 | 2.2 | 2820 | 0.86 |
| HS90L2-2 | 3 | 2820 | 0.86 |
| HS90L3-2 | 3.7 | 2820 | 0.80 |
| HS100L1-2 | 3 | 2840 | 0.83 |
| HS100L2-2 | 4 | 2850 | 0.86 |
| HS100M1-2 | 4 | 2830 | 0.84 |
| HS112M2-2 | 5.5 | 2840 | 0.85 |
| HS132S1-2 | 5.5 | 2890 | 0.86 |
| HS132S2-2 | 7.5 | 2900 | 0.86 |
| HS132M1-2 | 11 | 2920 | 0.88 |
| HS132M2-2 | 15 | 2920 | 0.88 |
| HS160M1-2 | 15 | 2920 | 0.87 |
| HS160M2-2 | 18.5 | 2920 | 0.87 |
| HS160M3-2 | 22 | 2920 | 0.87 |
Installation Dimensions
| FRAME | FLANGE | FRAME |
|---|---|---|
| 90L | 75/87 | 90/61 |
| 100L | 75/87 | 90/61 |
| 112M | 75/87 | 90/61 |
| 132S | 87 | 61 |
| 132M | 87 | 61 |
| 160M | 87 | 61 |
Warranty Information
Guarantee for 3 years from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
Certifications
Frequently Asked Questions
1. Q: What's the MOQ? 2. Q: Are you a factory or trading company?
A: A trial sample order is ok. A: Manufacturer. Focus on motors for more than 15 years.
3. Q: Can you accept using our logo? 4. Q: How can I get the sample?
A: Yes, we can do OEM for you. A: Usually, we suggest express for samples.
5. Q: What's the warranty period? 6. Q: What are your terms of payment?
A: 3 years from shipped on board date. A: 30% advance payment, balance before shipment.
