Big Capacity Electric Three Phase Induction Motor 380v 50hz For Agriculture Machinery

Price Negotiable

Price: negotiated

MOQ: 1pc

Delivery Time: 25 working days after received your payment

Brand: ZOZHI

Product Description

Big Capacity Electric Three Phase Induction Motor 380v 50hz For Agriculture Machinery

APPLICATIONS:

Y series three-phase induction motors are widely used in places where there doesn't exist combustible, explosive, or corrosive gas, and without any special requirements, such as machine tools, pumps, fans, transport machinery, mixer, agriculture machinery, and food machines, etc.

3 Phase Induction Motor PERFORMANCE CHART:

Model	Output HP KW		Current (A)	Speed (r/min)	Eff (%)	Power Factor	Eff (%)	Power Factor	Tstart/ Tn	Ist/ In	Tmax/ Tn
380V 5OHz Synchronous Speed 3000r/min (2 Poles)
Y-801-2	1	0.75	1.81	2830	75	0.84	73.8	0.79	2.2	6.5	2.3
Y-802-2	1.5	1.1	2.52	2830	77	0.86	76.5	0.81	2.2	7.0	2.3
Y-90S-2	2	1.5	3.44	2840	78	0.85	77.5	0.8	2.2	7.0	2.3
Y-90L-2	3	2.2	4.83	2840	80.5	0.86	79.7	0.82	2.2	7.0	2.3
Y-100L-2	4	3	6.39	2870	82	0.87	81.3	0.83	2.2	7.0	2.3
Y-112M-2	5.5	4	8.17	2890	85.5	0.87	84.8	0.83	2.2	7.0	2.3
Y-132S1-2	7.5	5.5	11.1	2900	85.5	0.88	84.9	0.86	2.0	7.0	2.3
Y-132S2-2	10	7.5	15	2900	86.2	0.88	85.5	0.86	2.0	7.0	2.3
Y-160M1-2	15	11	21.8	2930	87.2	0.88	86.5	0.86	2.0	7.0	2.3
Y-160M2-2	20	15	29.4	2930	88.2	0.88	87.6	0.85	2.0	7.0	2.3
Y-160L-2	25	16.5	35.5	2930	89	0.89	88.5	0.86	2.0	7.0	2.2
Y-160M-2	30	22	42.2	2940	89	0.89	88.1	0.87	2.0	7.0	2.2
Y-200L1-2	40	30	56.9	2950	90	0.89	88.7	0.86	2.0	7.0	2.2
Y-200L2-2	50	37	69.8	2950	90.5	0.89	89.7	0.86	2.0	7.0	2.2
Y-225M-2	60	45	83.9	2970	91.7	0.89	90.7	0.87	2.0	7.0	2.2
Y-250M-2	75	55	103	2970	91.5	0.89	90.6	0.86	2.0	7.0	2.2
Y280S-2	100	75	139	2970	92	0.89	91	0.86	2.0	7.0	2.2
Y280M-2	125	90	166	2970	92.5	0.89	91.4	0.86	2.0	7.0	2.2
Y315S-2	150	110	203	2980	92.5	0.89	91.4	0.86	1.8	6.8	2.2
Y315M-2	180	132	242	2980	93	0.89	91.8	0.87	1.8	6.8	2.2
Y315L1-2	220	160	292	2980	93.5	0.89	91.9	0.87	1.8	6.8	2.2
Y315L2-2	270	200	365	2980	93.5	0.89	92.3	0.87	1.8	6.8	2.2
Y355M-2	340	250	444	2980	94.5	0.9	93.3	0.88	1.6	7.0	2.2
Y355L-2	430	315	556	2980	95	0.9	93.9	0.88	1.6	7.1	2.2
380V 5OHz Synchronous Speed 1500r/min (4 Poles)
Y-801-4	0.75	0.55	1.51	1390	73	0.76	71.5	0.66	2.4	6.0	2.3
Y-802-4	1	0.75	2.01	1390	74.5	0.76	73	0.67	2.3	6.0	2.3
Y-90S-4	1.5	1.1	2.75	1400	78	0.78	77	0.71	2.3	6.5	2.3
Y-90L-4	2	1.5	3.65	1400	79	0.79	77.5	0.72	2.3	6.5	2.3
Y-100L1-4	3	2.2	5.03	1430	81	0.82	80.3	0.74	2.2	7.0	2.3
Y-100L2-4	4	3	6.82	1430	82.5	0.81	81.6	0.75	2.2	7.0	2.3
Y-112M-4	5.5	4	8.77	1440	84.5	0.82	83.3	0.76	2.2	7.0	2.3
Y-132S-4	7.5	5.5	11.69	1440	85.5	0.84	84.2	0.78	2.2	7.0	2.3
Y-132M-4	10	7.5	15.4	1440	87	0.85	86.1	0.8	2.2	7.0	2.3
Y-160M-4	15	11	22.6	1460	88	0.84	87.4	0.79	2.2	7.0	2.3
Y-160L-4	20	15	30.3	1460	88.5	0.85	87.8	0.8	2.2	7.0	2.3
Y-180M-4	25	18.5	35.9	1470	91	0.86	89.9	0.81	2.2	7.0	2.2
Y-180L-4	30	22	42.5	1470	91.5	0.86	90.7	0.81	2	7.0	2.2
Y-200L-4	40	30	56.8	1470	92.2	0.87	91.3	0.82	2	7.0	2.2
Y-225S-4	50	37	70.4	1480	91.8	0.87	91.1	0.84	1.9	7.0	2.2
Y-225M-4	60	45	84.2	1480	92.3	0.88	91.6	0.85	1.9	7.0	2.2
Y-250M-4	75	55	103	1480	92.6	0.88	91.5	0.84	2	7.0	2.2
Y280S-4	100	75	140	1480	92.7	0.89	91.7	0.84	1.9	7.0	2.2
Y280M-4	125	90	164	1480	93.5	0.89	92.4	0.85	1.9	7.0	2.2
Y315S-4	150	110	201	1480	93.5	0.89	92.5	0.86	1.8	6.8	2.2
Y315M-4	180	132	240	1490	94	0.89	92.8	0.86	1.8	6.8	2.2
Y315L1-4	220	160	289	1490	94.5	0.89	93.2	0.86	1.8	6.8	2.2
Y315L2-4	270	200	361	1490	94.5	0.89	93.2	0.86	1.8	6.8	2.2
Y355M-4	340	250	459	1485	94.7	0.87	93.6	0.87	1.6	6.8	2.2
Y355L-4	430	315	576	1485	95.2	0.87	94.1	0.87	1.6	6.9	2.2
380V 5OHz Synchronous Speed 1000r/min (6 Poles)
Y-801-6	0.5	0.37	1.2	900	70.5	0.68	68	0.59	2	5.5	2.2
Y-802-6	0.75	0.55	1.45	900	71.5	0.68	68	0.59	2	5.5	2.2
Y-90S-6	1	0.75	2.25	910	72.5	0.7	70.5	0.61	2	5.5	2.2
Y-90L-6	1.5	1.1	3.16	910	73.5	0.72	72	0.61	2	5.5	2.2
Y-100L-6	2	1.5	3.97	940	77.5	0.74	76.3	0.66	2	6.0	2.2
Y-112M-6	3	2.2	5.61	940	80.5	0.74	79.2	0.66	2	6.0	2.2
Y-132S-6	4	3	7.23	960	83	0.76	82	0.69		6.5	2.2
Y-132M1-6	5.5	4	9.4	960	84	0.77	83.1	0.7	2	6.5	2.2
Y-132M2-6	7.5	5.5	12.6	960	85.3	0.79	84.4	0.72	2	6.5	2.2
Y-160M-6	10	7.5	17	970	86	0.79	85.2	0.72	2	6.5	2
Y-160L-6	15	11	24.6	970	87	0.79	86.6	0.72	2	6.5	2
Y-180L-6	20	15	31.4	970	89.5	0.81	88.5	0.75	1.8	6.5	2
Y-200L1-6	25	18.5	37.7	970	89.8	0.83	88.7	0.77	1.8	6.5	2
Y-200L2-6	30	22	44.6	970	90.2	0.83	89.3	0.78	1.8	6.5	2
Y-225M-6	40	30	59.5	980	90.2	0.85	89.6	0.8	1.7	6.5	2
Y-250M-6	50	37	72	980	90.8	0.86	90.4	0.81	1.8	6.5	2
Y280S-6	60	45	85.4	980	92	0.87	91.2	0.82	1.8	6.5	2
Y280M-6	75	55	104	980	92	0.87	91.5	0.81	1.8	6.5	2
Y315S-6	100	75	141	990	92.8	0.87	92.3	0.82	1.6	6.5	2
Y315M-6	125	90	169	990	93.2	0.87	92.8	0.83	1.6	6.5	2
Y315L1-6	150	110	206	990	93.5	0.87	92.9	0.83	1.6	6.5	2
Y315L2-6	180	132	246	990	93.8	0.87	93.1	0.83	1.6	6.5	2
Y355M1-6	220	160	300	990	94.1	0.86	93.4	0.84	1.9	6.7	2
Y355M2-6	270	200	374	990	94.3	0.86	93.6	0.84	1.9	6.7	2
Y355L-6	340	250	465	990	94.7	0.86	94	0.84	1.9	6.7	2
380V 5OHz Synchronous Speed 750r/min (8 Poles)
Y-132S-8	3	2.2	5.85	710	80.5	0.71	79.7	0.62	2	5.5	2
Y-132M-8	4	3	7.72	710	82	0.72	81.2	0.64	2	5.5	2
Y-160M1-8	5.5	4	9.91	720	84	0.73	83.6	0.64	2	6.0	2
Y-160M2-8	7.5	5.5	13.3	720	85	0.74	84.4	0.66	2	6.0	2
Y-160L-8	10	7.5	17.7	720	86	0.75	85.1	0.68	2	5.5	2
Y-180L-8	15	11	24.8	730	87.5	0.77	86.9	0.7	1.7	6.0	2
Y-200L-8	20	15	34.1	730	88	0.76	87.3	0.71	1.8	6.0	2
Y-225S-8	25	18.5	41.3	730	89.5	0.76	88.5	0.7	1.7	6.0	2
Y-225M-8	30	22	47.6	730	90	0.78	88.8	0.71	1.8	6.0	2
Y-250M-8	40	30	63	740	90.5	0.8	90	0.72	1.8	6.0	2
Y280S-8	50	37	78.2	740	91	0.79	90.2	0.72	1.8	6.0	2
Y280M-8	60	45	93.2	740	91.7	0.8	91.1	0.74	1.8	6.0	2
Y315S-8	75	55	114	740	92	0.8	91.5	0.74	1.6	6.5	2
Y315M-8	100	75	152	740	92.5	0.81	92	0.76	1.6	6.5	2
Y315L1-8	125	90	179	740	93	0.82	92.6	0.77	1.6	6.5	2
Y315L2-8	150	110	218	740	93.3	0.82	92.8	0.78	1.6	6.3	2
Y355M1-8	180	132	260	740	93.8	0.81	93.3	0.79	1.9	6.3	2
Y355M2-8	220	160	314	740	94	0.81	93.5	0.79	1.9	6.3	2
Y355L-8	270	200	392	740	94.3	0.81	93.8	0.79	1.9	6.3	2

USABLE RANGE:

Y series 3 phase induction motors are widely used in places where not exists combustible, explosive, or corrosive gas, and without any special requirements, such as machine tools, pumps, fans, transport machinery, mixer, agriculture machinery, food machines, etc.

PRODUCT PARAMETER:

1. BRAND: CHIMP

2. RATED VOLTAGE: 380V

3. MODEL: Y series

4. RATED FREQUENCY: 50Hz (or 60Hz)

5. PRODUCT CATEGORY: an electric motor

6. PROTECTION CLASS: IP44 (or IP54)

7. BASE CENTER HEIGHT: 80-315mm

8. INSULATION CLASS: B

9. POWER RANGE: 0.55-220kw

10. WORK SYSTEM: S1

3 Phase Induction Motor ADVANTAGE:

1. Outstanding performance

2. High efficiency

3. Energy-saving

4. High starting torque

5. Low noise

6. Little vibration

7. Reliable operation and easy maintenance

3 Phase Induction Motor GUARANTEE:

3 phase induction motor Guarantee is one year from the shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.

OUR SERVICE:

1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and samples making, also we can advise how to make the products according to customers' target prices.

FAQ:

1. Q: What's the MOQ?
A: We accept one piece.

2. Q: Are you a factory or trading company?
A: We are a manufacturer.

3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.

4. Q: What's the warranty period?
A: 1 year.

5. Q: What are the terms of payment?

A: T/T. 30% deposit and 70% against the BL copy or 100% LC at sight.
