High Powert Electric Motor Water Pump For Swimming Pool , Long Operating Life
High Power Electric Motor Water Pump For Swimming Pool, Long Operating Life
ELECTRIC MOTOR WATER PUMP FEATURES:
- All critical components use high-strength engineering plastics and with a high-quality wear-resistant mechanical seal
- Frame equipped with specialized abs plastic mounting bracket
- Pump applies for a low noise standard motor, with thermal protector from the U.S.A.
- The Motor is with high-temperature resistance bearings ensure long operating life
- Complete separation of water and the shaft make the pump safe and reliable
ELECTRIC MOTOR WATER PUMP APPLICATION:
- The pump is suitable for hydromassage bathtub
- Plastic feet, a good protection performance is sea-farming for seawater convey
OPERATING CONDITIONS:
- Max.working pressure:0.3MPa
- Medium temperature:5-50℃
- Maximum environment temperature + 40℃
Optional Function:Timer & No Water Protection
TECHNICAL DATA:
| Model | Output | Volt | R.P.M. | Q.Max | H.Max | Insulation Class | Protection Grade | LxWxH | N.W. |
| HP / KW | (l/min) | (m) | (mm) | (Kg) | |||||
| DXD-750 | 1 / 0.75 | 230v/50Hz | 2850 | 300 | 10 | B | IPX5 | 400x170x220 | 8 |
| DXD-900 | 1.2 / 0.9 | 230v/50Hz | 2850 | 317 | 11 | B | IPX5 | 400x170x220 | 9.2 |
| DXD-1100 | 1.5 / 1.1 | 230v/50Hz | 2850 | 342 | 12 | B | IPX5 | 400x170x220 | 9.6 |
Other voltages and frequencies available on request
Electric Motor Water Pump GUARANTEE
Electric motor water pump guarantee is for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
F.A.Q.
1. Q: What's the M.O.Q.?
A: Trial sample order is ok.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do O.E.M. for you.
4. Q: How can I get the pump?
A: Usually, we suggest we express for samples. If the volume reaches one m³, the Seaway will be better.
5. Q: What's the warranty period?
A: 1 year.
