Energy Saving Electric Motor Water Pump 1.5HP / 1.1KW With 9M Max Suction , Stainless Steel
Energy Saving Electric Motor Water Pump 1.5HP / 1.1KW With 9M Max Suction, Stainless Steel
Application
QB series pump is suitable for pumping clean water and fluids which are not chemically aggressive to the pump components. They are extremely reliable, economical, and simple to use. They are particularly suitable for domestic applications such as the automatic distribution of water from small and medium-sized surge tanks, watering gardens, etc. These pumps should be installed in a covered area, protected against the weather.
Electric Motor Water Pump Technical Data
| MODEL | POWER | MAX.FLOW l/min |
MAX.HEAD m |
SUCT m |
INLET/ OUTLET |
G.W kg |
PACKING DIMENSION cm |
|
| KW | HP | |||||||
| QB-90 | 1.1 | 1.5 | 90 | 60 | 9 | 1½ "x1½" | 22 |
425x200x220
|
Other voltages and frequencies available on request
Structural Characteristics
Pump body: Cast Iron/Brass
Coil Wire: Copper
Impeller: Brass
Bearing: C&U/NSK/SKF
Insulation class: B and F
Protection class: IP44 or IP54
Mechanical seal: Carbon-ceramic/Stainless steel
Shaft: 45# Steel / Stainless steel 420
Single-phase motor with Thermal protector
Structural Characteristic:
| Main Specification | Standard | Optional |
| Transmission medium | Clean Water | |
| Pump body | Cast Iron | |
| Impeller | Brass | |
| Motor housing | Aluminum | |
| Stator&Rotor | 1. Cold-rolled silicon steel sheet by a high-speed punching machine. 2. 100% high-quality copper wire | |
| Front cover | Cast Iron | Brass plate embedded to avoid impeller jam |
| Bearing | Chinese Best Quality Bearing | NSK, SKF, or on request |
| Mechanical seal | Graphene/Ceramic | Silicon Carbon |
| Shaft | Carbon Steel | Stainless Steel |
| Insulation | Class B | Class F |
| Protection | IP44 | IP54 |
| Voltage | 220-240V Single Phase | On Request |
| Frequency | 50HZ | 60HZ |
| thermal protection | No | Yes |
| Automatic Pressure Control System | No | Yes |
| Cooling Type | External Ventilation | |
| Max. Suction lift | 9M | |
| Max. Fluid Temperature | +60℃ | |
| Max. Environment Temperature | +40℃ | |
| Installation | Horizontal | |
| Connect Type | Thread | |
| CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC | ||
Shipping & Payment
1.FedEx/DHL/UPS/TNT for samples
2.Batch goods delivered by sea
3.Customers specifying freight forwarders or negotiable shipping methods
4.Delivery Time:7-15 days for samples; 25-30 days for batch goods
5.30%T/T or 100%LC, balance against the copy of B/L
Electric Motor Water Pump Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
FAQ
1. Q: What’s the MOQ?
A: Trial sample order is ok.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: How can I get the pump?
A: Usually, we suggest express for samples. If the volume reaches 1m³, the Seaway will be better.
5. Q: What’s the warranty period?
A: 1 year.
