Plastic Cooling Motor Fan Blade Easy Spare Parts Y2 series Electric Motor

Description:

Electric Motor Cooling Fan Blades are used in electric motors for cooling purposes, The wide assortment of Electric Motor Cooling Fan Blade that we offer is available in various sizes

Applications:

 Y2 series cast iron asynchronous three-phase electric motors

 Ms series aluminum housing ac motors

 Y2(IE2, IE3) high-efficiency 3 phase motors

Advantages:

• Fast heat dissipation
• Strong Flexibility
• Easy to assembly

DATASHEET

	NO.	Item	A	B	C	D	No.of blade
	1	Y2-63	11.2	90	16	20	5
	2	Y2-63T	11.2	106	15	20	5
	3	Y2-71	14.2	90	20	20	5
	4	Y2-71T	14.2	120	18.5	20	7
	5	Y2-80-2	19.2	100	22	26	5
	6	Y2-80-4/6T	19.2	130	22	25	7
	7	Y2-90-2	24.2	110	27	35	5
	8	Y2-90-2T	19.2	135	20.5	31.5	7
	9	Y2-90-4/6	24.2	130	27	40	7
	10	Y2-90-4/6T	19.2	155	23	36	7
	11	Y2-100	28.2	130	27	40	5
	12	Y2-112-2	28.2	155	30	40	5
	13	Y2-112-4/6	28.2	185	30	45	7
	14	Y2-132-2	38.2	185	35	45	5
	15	Y2-132-4/6	38.2	200	35	50	7
	16	Y2-160-2	42	180	40	60	5
	17	Y2-160-4/6	43	240	40	70	7
	18	Y2-180-2/4	52	240	50	90	5
	19	Y2-180-6/8	52	290	50	90	9
	20	Y2-200-2	58	260	50	90	5
	21	Y2-200-4/6/8	58	300	50	90	9
	22	Y2-225-2	58	265	55	100	5
	23	Y2-225-4/6	58	370	55	100	9
	24	Y2-250-2	63	270	60	110	5
	25	Y2-250-4/6	63	380	60	110	9
	26	Y2-280-2	68	280	60	110	5
	27	Y2-280-4/6	68	400	65	130	9
	28	Y2-315-2	80	300	80	150	5
	29	Y2-315-4	90	420	80	150	9
	30	Y2-315-6/8	90	460	80	150	9

  Pictures:

Guarantee:

Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.

Our service:

1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and samples making, also we can advise how to make the products according to customers' target prices.

FAQ:
