IE2 MS801-2 Electric Motors 230V/400V Marelli Type Industrial Motors Aluminium Housing
IE2 MS801-2 Electric Motors 230V/400V Marelli Type Industrial Motors Aluminium Housing
1. novel design, good-looking, maintained easily
2. use class F insulation, safe and reliable
3. self-cooled squirrel-cage motor of the enclosed type
4. Use superior seton molding process
5. wide usage, be suitable for many kinds of machines
IE3 Motor INSULATION MATERIAL:
2. Use DMD high-temperature insulating paper, combined with mylar limpness composite material and polyester non-woven fabrics thin film.
3. Use a High temperature resistant 180℃ Cable line.
4. Use Oxyhydrogen carbon-free welding technology. Dense flame, strong welding, and carbon embrittlement-free.
OPERATING LIMITS:
Ambient Temperature: -15°C~40°C
Altitude: not exceed 1000 Meter
Rated Voltage: 230/400V
Rated Frequency: 50Hz/60Hz
Protection Class: IP44, IP54, IP55
Insulation Class: B/F
Cooling Method: IC0141
Working Duty: S1(Continuous)
Humidity: Lower than 90%
Connection: Star-connection for up to 3kW; Delta-connection for 4kW and above
IE3 Motor Products Details:
| Site conditions | Motors are suitable for the most working environment at a temperature from -15°C t0 +40°C and an altitude below 1000 meters. |
| Insulation | The motors' insulation system is set to Class F(105K), examined by Class B(80K), which ensures the life span and reliability of the motors. |
| Motor protection | Motors can be installed with PTC, PT100 used winding and bearing temperature measurement on request. |
| Voltage and frequency | The standard voltage and frequency is 380V 50HZ and can be set to any single voltage in the range of 200-660V at a frequency of 50 or 60HZ. The motors work well within variations of ±5% from the rated voltage. |
| Vibration | Motors are designed for vibration class A; vibration class B is available on request. |
| Duty | Continuous(S1) |
| Cooling and ventilation | The standard cooling method is enclosed fan cooled(TEFC) following IC411 of IEC60034-6. Standard motors are equipped with auxiliary plastic fans. |
| Winding | 100% Copper Wire |
| Protection class | The standard protection class is IP54/IP55, which can be used in humid and dusty environments. Higher degrees of protection are available. |
| Quality assurance | From the first line of production designing till the finishing procedure, obey ISO9001 documented quality system. |
PERFORMANCE CHART:
IE3 Motor GUARANTEE:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
OUR SERVICE:
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available. Feel free to contact us.
4. We provide one-stop services for all goods produced by ourselves, from designing, printing to processing. Customers can provide the design according to your request and sample making. Also, we can advise how to make the products according to customers' target prices.
FAQ:
1. Q: What's the MOQ?
A: We accept one piece.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: What's the warranty period?
A: 1 year.
5. Q: What are the terms of payment?
A: T/T. 30% deposit and 70% against the BL copy or 100% LC at sight.
