2HP 1.5KW 230V Single Asynchronous Motor MY Series Capacitor Operation 2800RPM
2HP 1.5KW 230V Single Asynchronous Motor MY Series Capacitor Operation 2800RPM
Electric Motor Water Pump
MY series aluminum housing three-phase asynchronous motors, with the latest design in entirety, are made of selected quality materials and conform to the IEC standard.
ML motors have good performance, safety and reliable operation, nice appearance, and can be maintained very conveniently while with low noise. Little vibration, at the same time, lightweight and simple construction. Therefore, these motors can be used for general drive.
1. Customized Production is available.
2. Supply for OEM and After Markets.
3. 100% tested for quality before shipment
4. Certificate and Guarantee: ISO 9001:2008 / one year
5. package: carton&pallet
| Type | Output | Voltage | Current | Speed | Eff. | Power | Locked Torque | Maximum Torque | Locked Current |
| (KW) | (V) | (A) | (r.p.m) | (%) | Factor | Rated Torque | Rated Torque | Rated Current | |
| MY5612 | 0.09 | 220 | 0.75 | 2800 | 56 | 0.92 | 0.5 | 1.7 | 3 |
| MY5622 | 0.12 | 220 | 0.94 | 2800 | 60 | 0.92 | 0.5 | 1.7 | 4 |
| MY6312 | 0.18 | 220 | 1.48 | 2800 | 60 | 0.92 | 0.4 | 1.7 | 5 |
| MY6322 | 0.25 | 220 | 1.96 | 2800 | 63 | 0.92 | 0.4 | 1.7 | 7 |
| MY7112 | 0.37 | 220 | 2.73 | 2800 | 67 | 0.92 | 0.35 | 1.7 | 10 |
| MY7122 | 0.55 | 220 | 3.88 | 2800 | 70 | 0.92 | 0.35 | 1.7 | 15 |
| MY8012 | 0.75 | 220 | 5.15 | 2800 | 72 | 0.92 | 0.33 | 1.7 | 20 |
| MY8022 | 1.1 | 220 | 7.02 | 2800 | 75 | 0.95 | 0.33 | 1.7 | 30 |
| MY90S-2 | 1.5 | 220 | 9.44 | 2800 | 76 | 0.95 | 0.3 | 1.7 | 45 |
| MY90L-2 | 2.2 | 220 | 13.67 | 2800 | 77 | 0.95 | 0.3 | 1.7 | 65 |
| MY100L-2 | 3 | 220 | 17.8 | 2800 | 78 | 0.98 | 0.3 | 1.7 | 92 |
| MY5614 | 0.06 | 220 | 0.58 | 1400 | 50 | 0.9 | 0.45 | 1.7 | 2 |
| MY5624 | 0.09 | 220 | 0.83 | 1400 | 52 | 0.9 | 0.45 | 1.7 | 3 |
| MY6314 | 0.12 | 220 | 1.1 | 1400 | 55 | 0.9 | 0.4 | 1.7 | 3.5 |
| MY6324 | 0.18 | 220 | 1.62 | 1400 | 56 | 0.9 | 0.4 | 1.7 | 5 |
| MY7114 | 0.25 | 220 | 2.02 | 1400 | 61 | 0.92 | 0.35 | 1.7 | 7 |
| MY7124 | 0.37 | 220 | 2.95 | 1400 | 62 | 0.92 | 0.35 | 1.7 | 10 |
| MY8014 | 0.55 | 220 | 4.25 | 1400 | 64 | 0.92 | 0.35 | 1.7 | 15 |
| MY8024 | 0.75 | 220 | 5.45 | 1400 | 68 | 0.92 | 0.32 | 1.7 | 20 |
| MY90S-4 | 1.1 | 220 | 7.45 | 1400 | 71 | 0.95 | 0.32 | 1.7 | 30 |
| MY90L-4 | 1.5 | 220 | 9.83 | 1400 | 73 | 0.95 | 0.3 | 1.7 | 45 |
| MY100L1-4 | 2.2 | 220 | 13.6 | 1400 | 76 | 0.95 | 0.3 | 1.7 | 65 |
| MY100L2-4 | 3 | 220 | 18 | 1400 | 77 | 0.95 | 0.3 | 1.7 | 88 |
Electric Motor Water Pump Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
