4 Pole Three Phase Electric Motor 0.08HP 0.06KW 230/400V 1400RPM 50HZ MS561-4

4 Pole Three Phase Electric Motor 0.08HP 0.06KW 230/400V 1400RPM 50HZ MS561-4

MS Three Phase Electric Motor

Brief Introduction

• MS series aluminum housing three-phase asynchronous motors, with the latest design in entirety, are made of selected quality materials and conform to the IEC standard.
• MS motors have good performance, safety and reliable operation, nice appearance, and can be maintained very conveniently while with low noise. Little vibration, at the same time, lightweight and simple construction. Therefore, these motors can be used for general drive.

1. Customized Production is available.

2. Supply for OEM and After Markets.

3. 100% tested for quality before shipment

4. Certificate and Guarantee: ISO 9001:2008 / one year

5. package: carton&pallet

Detailed Product Description

1.CE certificate
2.Copper wire
3.Cold-rolled silicon steel sheet

Specifications
1) Frame sizes: 56-180
2) Rated power: 0.09-18.5kw
3) Rated voltage: 220/380V,380/660V, or on your request

4) Frequency: 50Hz, 60Hz, or 50/60Hz
5) Protection class: IP54, IP54
6) Insulation class: B,F,H
7) Materials: Aluminum

8) EFF: EFF3, EFF2, EFF1
9) Poles: 2, 4, 6, 8
10) Cooling method: IC411 (total-enclosed fan-cooled type)
11) Mounting types: B3/B5/B14/B15/B34/B35

12) Operating mode: S1
13) Connection: "Y" type for 3kW and downwards, "D" type for 4kW and upwards
14) Ambient temperature: -15°C < θ < 40°C
15) The altitude should be lower than 1,000m above the sea level
16) Special motors can be designed according to customers' requirements

Electric Motor Water Pump Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
