Single Row 6201-RS/Z/2RS NSK 6201 Deep Groove Ball Bearing

Price Negotiable

Price: $0.10-$3.00

MOQ: 10pcs

Delivery Time: it is 2-5 days if in stock,7-15 days if not stock

Brand: NSK

Product Description

High Precision Bearing 6201-RS/Z/2RS NSK 6201 Bearing Deep Groove Ball Bearing

Product Description

Product Name	High Precision Bearing 6201-RS/Z/2RS NSK 6201 Bearing
Model Number	Deep Groove Ball Bearing 6201-RS/Z/2RS
Shaft Size	12mm
Product Material	Chrome steel
Precision Grade	P0 P6 P5 P4 P2 are all available
Cage Material	steel, brass, nylon
Weight	0.039KG
Service	Agent, OEM, customized
Delivery Time	Generally, it is 2-5 days if in stock,7-15 days if not stock, or it is according to the customer's requirements
Features	Long life and high quality
	High precision, low noise with strict controlling of the quality
	High loading by the advanced high-technical design
	Most competitive price, factory direct
	OEM service offered, to meet the customer's requirements
Price Terms	EXW, FOB, CFR, CIF
Package	PE bag+paper box+outer carton+wooden box+pallet, or as customers' requirement

Deep groove ball bearings mainly take radial load, but also support radial and axial load. When the only bear radial load, the contact angle is zero. When the deep groove ball bearings with a larger radial clearance, the performance with angular contact bearings can bear a large axial load, deep groove ball bearing friction coefficient is small, speed is also high.

Main Features:

1. Deep groove ball bearings are most representative of the rolling bearing, widely used.
2. For high speed or high-speed operation, and very durable, without regular maintenance.
3. This kind of bearing friction coefficient is a small, extremely high speed, simple structure, low cost, easy to achieve high manufacturing precision.
4. Size range and diverse forms, used in precision instruments, low noise motors, automobiles, motorcycles, and general machinery industries, the machinery industry, the most widely used class of bearings.
5. The main radial load also can withstand a certain amount of axial load.

Dimensions
d 12 mm
D 32 mm
B 10 mm
d1 ≈ 18.45 mm
D2 ≈ 27.34 mm
r1,2 min. 0.6 mm

Abutment dimensions
da min. 16.2 mm
da max. 18.4 mm
Da max. 27.8 mm
ra max. 0.6 mm

More type:

Bearing NO.	Principal dimension			Weight (Kg)	Bearing NO.	Principal dimension			Weight (Kg)
	L.D.	O.D.	Width			I.D.	O.D.	Width
6000-Z/2Z/RS/2RS	10	26	8	0.019	6214-Z/2Z/RS/2RS	70	125	24	1.04
6001-Z/2Z/RS/2RS	12	28	8	0.021	6215-Z/2Z/RS/2RS	75	130	25	1.08
6002-Z/2Z/RS/2RS	15	32	9	0.026	6216-Z/2Z/RS/2RS	80	140	26	1.38
6003-Z/2Z/RS/2RS	17	35	10	0.036	6217-Z/2Z/RS/2RS	85	150	28	1.75
6004-Z/2Z/RS/2RS	20	42	12	0.07	6218-Z/2Z/RS/2RS	90	160	30	2.18
6005-Z/2Z/RS/2RS	25	47	12	0.08	6304-Z/2Z/RS/2RS	20	52	15	0.14
6006-Z/2Z/RS/2RS	30	55	13	0.12	6305-Z/2Z/RS/2RS	25	62	17	0.22
6007-Z/2Z/RS/2RS	35	62	14	0.16	6306-Z/2Z/RS/2RS	30	72	19	0.35
6008-Z/2Z/RS/2RS	40	68	15	0.19	6307-Z/2Z/RS/2RS	35	80	21	0.42
6009-Z/2Z/RS/2RS	45	75	16	0.24	6308-Z/2Z/RS/2RS	40	90	23	0.63
6010-Z/2Z/RS/2RS	50	80	16	0.28	6309-Z/2Z/RS/2RS	45	100	25	0.83
6204-Z/2Z/RS/2RS	20	47	14	0.1	6406-Z/2Z/RS/2RS	30	90	23	0.72
6205-Z/2Z/RS/2RS	25	52	15	0.12	6407-Z/2Z/RS/2RS	35	100	25	0.82
6206-Z/2Z/RS/2RS	30	62	16	0.19	6408-Z/2Z/RS/2RS	40	110	27	1.16
6207-Z/2Z/RS/2RS	35	72	17	0.27	6409-Z/2Z/RS/2RS	45	120	29	1.55
6208-Z/2Z/RS/2RS	40	80	18	0.37	6410-Z/2Z/RS/2RS	50	130	31	1.91
