DP-550A 0.55KW 0.5HP Cast Iron Surface Mounted Deep Well Pumps

Surface Mounted Deep Well Pumps with Cast Iron pump bodies, and a variety of performances, and motor sizes for water transfer, pressure systems, irrigation, and supporting equipment. Taking your water from wells, boreholes, streams, or any underground water source, and delivering it to your house, garden, farm, or building.

Deep Well Pump

Working　Condition
Max. fluid temperature +60℃

Max. ambient temperature +40℃
Max. solid impurity:0.1%,Max. particle size: 0.2mm.

Construction

Pump

Pump Body: Cast iron/Brass/Stainless steel
Impeller: Brass/P.P.O

Mechanical Seal: Carbon/Ceramic/Stainless steel

Motor
Single Phase
Heavy-Duty Continuous Work
Motor Housing: Aluminum
Shaft: Carbon Steel / Stainless Steel
Insulation: Class B / Class F
Protection: IP44 / IP54
Cooling: External Ventilation
Construction and safety standards in compliance with IEC

220V/50HZ.60HZ 110V/50HZ.60HZ 220v.110v/50hz.60hz are available on request.
