0.75HP 0.55KW Single Phase Centrifugal Water Pump For Farm Irrigation
0.75HP 0.55KW Single Phase Centrifugal Water Pump For Farm Irrigation
Centrifugal Water Pump
These pumps are suitable for pumping clean water and fluids which are not chemically aggressive to pump components. For extremely reliable, big capacity and high head, widely using in the domestic and civil applications, transferring water, irrigating gardens, etc. These pumps should be installed in a covered area, protected against the weather.
Application Feilds:
Widely used in small industrial irrigation, gardens, vegetable greenhouse watering, aquaculture water supply, drainage, etc.
Working Condition
Max. fluid temperature +60℃ Max. ambient temperature +40℃ Max. solid impurity:0.1%, Max. particle size: 0.2mm.
TECHNICAL DATA (220~240V/50HZ)
| Single-phase Motor | n=2850r/min | ||||||
| Model | Input max | Output Power | Current | Q.max | H.max | Suct. max | |
| kW | kW | HP | A | L/min | m | m | |
| 1.5DKm-16 | 1.1 | 0.55 | 0.75 | 5.2 | 180 | 16 | 9 |
| 1.5DKm-20 | 1.5 | 0.75 | 1 | 7 | 240 | 20 | |
| 2DKm-16 | 1.5 | 1.1 | 1.5 | 7 | 480 | 21 | |
| 2DKm-20 | 2 | 1.5 | 2 | 9.6 | 540 | 23 | |
Other voltages and frequencies are available on request.
Our Customer
Centrifugal Water Pump Guarantee:
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
Our Service:
1. Free maintenance within 12 months guarantee.
2. We cooperate with customers to design and develop a new product.
3. We'd like to assist you in arranging delivery things, test things, or others on your request.
4. Customize production.
1. We are a professional manufacturer with more than 13 years experience in Electric motor
2. We are Made in China Gold Supplier
3.we test the material before production and three to four times when producing to ensure the goods in good quality, also we produce according to request
4.we can be your OEM manufacturer with your authorization of the brand.
FAQ:
Q: What’s the MOQ?
A: We accept one piece.
Q: Are you a factory or trading company?
A: We are a manufacturer.
Q: Can you accept to use our logo?
A: Yes, we can do OEM for you.
Q: What’s the warranty period?
A: 1 year.
Q: What are the terms of payment?
A: T/T. 30% deposit and 70% against the BL copy or 100% LC at sight.
