Low Power Consumption LED Curtain Display Aluminum Cabinet Material
P37.5 Mesh LED Display Curtain DIP546 lamps outdoor full color video screen
Product description:
- DIP546 led encapsulation confirm high brightness,and good uniformity;
- High definition, Good uniformity；
- Easy bend for defferent shapes,like S, Circle, Curve etc, also can Foldable from Horizontal and Vertical;
- Super slim with minimum thickness of 55mm;
- Low power consumption, low noise created, low transportation costs, and low installation costs;
- Streamline design and beautiful appearance;
- High definition, Good uniformity,long life span;
- It is just different from the traditional one;
- Good waterproof and dustproof, IP65, for indoor and outdoor use;
- Mesh design for good heat dissipation and good light transmission;
- Single module design, can dismantle by single module, fast and easy to maintain.
Aplication:
Our full color LED display are widely used in bank,museum,government project,shopping malls,
train station,big square,subway station,convention center,fitness hall,TV Shows,live show,banking,touring,gym,hotels.
Parameter:
| P37.50 Full Color LED Display Main Parameters | ||
| Visual Characteristics | Unit | Value |
| Pixel Pitch | mm | 37.5 |
| Pixel Density | Dots/sq.m | 711 |
| Pixel Configuration | DIP546 | |
| Cabinet Resolution | dots | 16×16 |
| Refresh Rate | Hz | ≥1200 |
| View Angle(H/V) | ° | 100/45 |
| Brightness | nits | ≥800 |
| Gray Scale | Bit | 16 |
| IP Rating | 65 | |
| Power Consumption(Max/Avg) | W/sq.m | 200/100 |
| Input Voltage(AC) | V | 110~220 |
| Modular Characteristics | ||
| Cabinet Size(W×H×D) | mm | 600×600×55 |
| Cabinet Material | Aluminum | |
| Cabinet Weight | Kg | 7 |
| Module Size(W×H) | mm | 600×600 |
| Environment | ||
| Operation Temperature | ºC | -20~+40 |
| Operating Humidity | 10%~90% | |
| Driving Mode | 1/4 Scan | |
| Control Distance | Cat 5E <100m,Single mode fiber<10Km | |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | ||
Our company:
OUR COMPANY leads the way in LED display manufacturing & technology. Its outdoor & indoor commercial advertising LED display, rental use LED display, fixed installation LED display, sports stadium perimeter LED display, mobile trailer LED display, water floating LED display, transparent LED curtain display, digital LED billboard, LED mesh display screen for skyscraper's decoration, arc LED display, LED components & complete LED full color video systems undergo stringent quality control at ISO 9001-certified manufacturing plants.
Why choose us:
- Quality advantage: From material to finished product, from design to produce, we control all steps;
- Price Advantage: We have the best competitive price at the market, also have the same even better quality;
- 100% QC inspection before shipping;
Project case:
