P1.667 Small Pitch HD LED Display Full Color Die Casting Aluminum Cabinet

Price Negotiable

Price: Negotiation

MOQ: 1 square meter

Delivery Time: 12-20 working days after received your payment

Brand: Shenzhen LED World

Product Description

P1.667 HD small pitch LED display screen 4 : 3 high refresh video wall

Features:

Full HD;
Seamless spliced,with smooth and vivid visual effect,perfect performance;
High resolution and definition of screen image, clear and non-flash screen image;
Cabinet Resolution(W*H) 160*120 210*157 250*187 Pixel Configuration 1R1G1B(in 3 n;
seamless splicing, image smoothness is high, the quality is good;
Seamless splicing, High brightness, good uniformity;good performance;
Refresh Frequency ≥2880Hz(Support High refresh rate, depend on the system configuration);
High Refresh Rate;
High density, high definition and high refresh rate up to 3000Hz.

Parameter:

	PH1.6 Indoor led video wall
No.	Parameter	Specification
1	Pixel Pitch(mm)	1.667
2	Pixel Density	360000pix/sq.m
3	LED Type	SMD1010
4	LED Wave Length(nm)	R:620-625/G:517.5-520/B:465-467.5
5	LED Luminous Intensity(mcd)	R:100~130/G:120~156/B:20~26
6	Viewing Angle	160°
7	Brightness	1000cd/M2
8	Drive Method	constant current
9	Driving IC	MBI5153
10	Color Depth	16bit
11	Refresh Rate(Hz)	1200
12	Frame Rate(Hz)	≥60
13	Brightness Adjustment	Manual/Auto/Program
14	Module Size(mm)	200×150
15	Module Resolution()	120×90
16	Cabinet Size(mm)	400×300
17	Cabinet Display Resolution()	240×180
18	Cabinet Type and Material	Die-casting Aluminum
19	Cabinet Weight(Kg)	5.0kg
20	Power Supply	5.0V 40A
21	Voltage(V)	AC 220V
22	Avg. Power Consumption	40W/cabinet
23	Max. Power Consumption	120W/cabinet
24	Service Access	Back maintenance
25	IP Grade	IP31
26	Operating Temp/Humidity	-20ºC~50ºC, 10~90%RH
27	Storage Temp/Humidity	-40ºC~60ºC, 10~90%RH
28	Lifetime(Normal Temp)	≥50000H
29	System Control	Nova/Linsn
30	Compliant Standard	CCC,CE,RoHs
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

FQA:

How about your quality control?
Quality control starts from strict raw material purchase.
Each product will run through aging test for 72 hours.
What kind of display we provide?
We have indoor/outdoor/rental taxi top /mobile LED display/LED stage/Irregular LED display for you choose;
How about your production ability?
We have 10 production lines with all series of automatic production machines.
Monthly production ability: 200,000pcs of led modules and 4,000sqm of assembled led displays;
Besides this product, may I have other options?
Yes, my dear friend. Many thanks for finish the details of this product. If it is not what you're looking for, you can also choose other items. we have HD indoor led display, full color for outdoor and indoor; Different cabinet, Steel Cabinet, Aluminum Cabinet, Die Cast Aluminum Cabinet, etc; The pixel pitch is from 1.5mm to 20mm. We also have LED advertising player and kinds of video processor;
Are you manufacturer of led display.If yes, in which city?
Yes, Our factory with 9000 square meters. And we're in SHENZHEN city, GUANGDONG Province;
Where is your company?
We are located in address:No.4 Bldg,Second Industrial Park of Baiwang,Baimang Village,Xili street,Nanshan District,Shenzhen,China;

Our service:

Under normal use and storage, Our Company will be responsible for the equipments;
Your inquiry related to our products or price will be replied in 24hrs;
We offer training for free;
Aging test at least 24 hours before shipment;
We also provide the operation manual, software, and so on. Any associated drawing of product and structure and some other professional suggestion will be provided too;
Factory visiting and inspecting is welcome;
Allow free training .You can send your engineer to our factory for training untill he knows all the operation；
We offered technical advice to you before buying our products;
