P2 / P2.5 / P5 Advertising LED Displays High Precision 10000 Hours
Price:
Negotiation
MOQ:
1 square meter
Delivery Time:
15-20 working days after received your payment
Brand:
Shenzhen LED World
Product Description
Synchronization P2 / P2.5 / P5 indoor advertising screens high precision.
Features:
- Most competitive price for the same model in the market;
- High refresh frequency, high grey level, and no dithering while displaying videos, can be used for live TV program, and The pixel correction technology is available.
- High resolution,wide view angle,short view distance available,eys friendly;
- High definition, good uniformity;
- High pixel density, high definition, colorful, rich perspective, long life span and energy-saving etc;
- High-Energy Saving
- Save 66% energy;
- Seamless spliced,with smooth and vivid visual effect,perfect performance;
- Ideal for close viewing distance;
- Wide view angle, good display performance and good cost performance;
- Good hot dissipation, without fans, no noise, beautiful looking, easy mounting without gap;
- Can be assembled with cabinets or on rackes with magnet, for led TV Screen, video wall, sign board etc;
- SMD LED encapsulated technology make slim thickness and good heat dissipation, energy-saving;
Application:
Our indoor ture color LED screen are widely used in 4S shop,park,advertisement, bar,Open Air exhibitions,backgound,show,power sector,commercial buildings,bars,live show,concert hall,restaurant,waiting room of station,stadium,Amusement parks,airport,large entertainment plaza,image promotion, golf course and so on .
Parameter:
| Pixel pitch | 2.0mm | 2.5mm |
| Pixel Configuration | 1R1G1B | 1R1G1B |
| LED component | SMD1010 | SMD2121 |
| Size of module | 160mm x 160mm | 160mm x 160mm |
| Resolution of module | 80x80 | 64x64 |
| Size of cabinet | 480mm x 480mm x 78mm | 480mm x 480mm x 78mm |
| Resolution of cabinet | 240x240 | 192x192 |
| Material of Cabinet | Die-casting Aluminum | Die-casting Aluminum |
| Weight of Cabinet | about 7KG/cabinet | about 7KG/cabinet |
| Brightness | >1000cd/sq.m | >1200cd/sq.m |
| Density | 250000dots/sq.m | 160000dots/sq.m |
| Best viewing angle | 140 /140 | 140 /140 |
| Best viewing distance | 1.5-20M | 2-30M |
| Maximum power consumption | 600W/sq.m | 600W/sq.m |
| Average power consumption | 300W/sq.m | 300W/sq.m |
| Driving method | 1/16 scan | 1/32 scan |
| Control method | Synchronization | Synchronization |
| Gray scale | 65536 | 65536 |
| Colors | 256*256*256 | 256*256*256 |
| Working voltage | AC220V/110V±10% | |
| Working temperature | -20ºC~+50ºC±10% | |
| Working humidity | 10% ~ 90% | |
| MTBF | 10,000 hours | |
| Frame frequence | 50/60Hz | |
| Refresh frequence | >3000Hz | |
| IP grade | IP31 | |
| Life Span | 100,000 hours | |
| Data transafer method | RJ45 | |
| Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. | |
| Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development | |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | ||
Our service:
- 1% spare parts offered FOC;
- Help you to choose suitable products within budget with most economy benefit;
- Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection;
- OEM service offered;
Product detail:
