Waterproof Truck Mobile LED Display With Nova Linsn System 1/5 Scan Mode
Price:
negotiable
MOQ:
1 pcs
Delivery Time:
10~18 working days after deposit received
Brand:
Shenzhen LED World
Product Description
Mobile trailer outdoor P8 truck led screen panel for advertising with nova linsn system .
Features:
- Anti-UV, anti-oxidation module prevents from deformation;
- IP65 for front,and IP54 for back , good waterproof, can be used for outdoor when it is raining;
- Can be done with single side or double sides,screen size can be customized if your quantity is larger More pictures for understanding well;
- Back installation for drivers,benefical to maintenance；
- The product is with convenient installation, and flight connectors connecting；
- Minimum space needed behind cabinet, only enough for structure & ventilation;
- Support multimedia playback;
Parameter:
| Unit Module | Item | Parameter |
| Model Number | LW-FO 8 | |
| Module size | 320mm*160mm | |
| Pixel pitch | 8mm | |
| Pixels Density | 15625dots/m2 | |
| Pixel configuration | 1R1G1B | |
| LED Package mode | SMD3535 | |
| Pixel resolution | 40dots(W)*20 dots(H) | |
| Max Power | 25W | |
| Module thickness | 17.05mm | |
| Weight | 0.38kg | |
| Drive type | Constant drive | |
| Scan mode | 1/5scan | |
| Port type | HUB75-A | |
| Brightness of white balance | ≥5600cd/m2 | |
| LED Cabinet | Dimension | 640mm*640mm |
| Monomer Module Number | 8 | |
| Power supply | 5V/40A*1 pcs | |
| Thermal discharge | fan 2pcs | |
| Pixel per cabinet | 80mm*80mm | |
| Best viewing distance | 8M~40M | |
| Best viewing angle | 160°(W) 120°(H) | |
| Temperature | storage:-35ºC~+85ºC | |
| working:-20ºC~+50ºC | ||
| Relative humidity | 10%-95% | |
| Thickness | 85mm | |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | 140W/m2 | |
| Max.Power consumption | ≤480W/m2 | |
| Current | ≤20mA(single LED) | |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
| Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | ≥1,200HZ | |
| Grey scale/colors | 4,096gray level/16.7M colors | |
| MTBF | ≥9,000hours | |
| Power switch | Automatic switch | |
| Display Mode | ≥800*600/1024*768 | |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | ||
Applications:
It can be widely used in leisure square, commercial real estate,surrounding,indoor stadium,municipal public buildings,exclusive agency,gym,Internet bar,railway stations and so on.
Our service:
The size can be change as you give, your customized lightings we can help you to design and put into product;
Service principles: Response in time, solve problems as soon as possible and ensure the use;
Factory visiting and inspecting is welcome;
Project case:
Package:
