SMD3528 Black Commercial Led Screens Outdoor For Night Club / Stadium
Price:
negotiable
MOQ:
1 square meter
Delivery Time:
10~18 days after receiving the deposit
Brand:
Shenzhen LED World
Product Description
P6 SMD3528 black Indoor Fixed LED Display 1/8 scan 192x192 module front service
Application:
Our full color LED display are widely used in public facilities,HR market,massage room,plaza,Outdoor Signage and advertisement,feast,ticket center,trade fair,night club,Internet bar,station waiting area,commercial real estate,bar,stores hospitals,stadium,mansion video wall and so on .
Features:
- the SMD triad technology, makes the screen when use ultra wide Angle of view and better surface smoothness and stability;
- High quality with Vivid visual effect ;
- Correction technology: the optimization of the LED screen visual effect, improve the quality of the LED screen, prolong the service life of LED screen, screen cost;
- RGB deep gray processing, rich colors, exquisite quality hd;
- Long-term brightness capacity throughout product lifetime;
- Buckle cabinet design makes it fast installation and dismantle, both for fixed installation and rental using;
Parameter:
| Item | Parameter |
| Pixel Pitch | P6mm |
| Encapsulation | SMD3528 black |
| Pixel Configuration | 1R1G1B |
| Driver Method | Scan1/8 |
| Color Match | R:G:B=3:6:1 |
| Module Size(H*W) | 192mm*192mm |
| Module Resolution(H*W) | 32*32dots |
| Cabinets Size(H*W) | 576*768mm |
| Pixel Density | 27777dots/M2 |
| Modules Weight | 15kg |
| Cabinet Material | Iron |
| Maintenance | Front service |
| Average Power Consumption | 400W/M2 |
| Max. Consumption | 1200W/M2 |
| Brightness | ≥2000CD/M2 |
| View Angle | H 120° /V 120° |
| Refresh Rate | ≥1200Hz |
| Frame Frequency | ≥30Hz |
| Color Depth | 14bit |
| Voltage Input | AC110V/220V±15% 40~65HZ |
| IP Rating | IP31(front/back) |
| Operating Temperature | -20ºC~60ºC , storage for :-30ºC~+90ºC |
| System Working Environment Humidity | 10%-90%RH |
| Life Span(Hours) | ≥55,000Hours |
| Best View Distance | 3-105meter |
| Color Temperature | 5600K±500 |
| Power Supply | G-energy(CE/UL) |
| Control Distance | <100meter by Internet Cable(without Relay); Fiber Cable > 500 meters |
| No-malfunction time(Avg.) | >5000hours |
| Control system | Linsn/Novastar |
| Compliant standard | CE, ROHS.ETL,UL.TUV.CCC,EMC |
| Information Sources | Many kinds of signal access: can input TV signals , DVD signals , DVI, S-VIDEO, RGB, VGA, and so on. |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |
Our service:
- Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on;
- Under normal use and storage, Our Company will be responsible for the equipments;
- All of our led display have proceeded aging test before shipment;
- Allow free training .You can send your engineer to our factory for training untill he knows all the operation；
Package:
