High Definition Clear Outdoor Rental Led Display Panel Full Color 500x1000 Cabinet
Price:
negotiable
MOQ:
1 square meter
Delivery Time:
12~20 working days after deposit received
Brand:
Shenzhen LED World
Product Description
High Definition Clear Outdoor Rental Led Display Panel Full Color 500x1000 Cabinet
Product Description:
- The same cabinet can be compatible with different pitches:P4.8/P3.91/P6.25Some pictures showing as belo for your reference:Some pictures showing below for your reference;
- Straight and curved cabinet design available for your fantastice event design;
- Achieve shaped and curved install function. Could be assembled with more different shapes to meet the different install design requirements of different application areas;
- It is very easy to calculate size of LED display;
- It is made of Slim aluminum panel 500mm W*1000mm H , ultra-thin and super-light, only 11KG per panel (22KG per square meter);
- The shapes can be outer curved ,inner curved ,flat and waved by using our specially designed angle regulator;
- Indoor and outdoor Full color led project screen.
- The same size cabinet can be compatible with different specification displays of different DOT pixels. (P3.9, P4.8, P5.68, P6.25);
- Die Casting Aluminum Cabinet LED Display screen
- Free angle shape assembly,adjustable angle from -15°~ 15°,meet the requirement of featured stage style；
- Magnets module design, 5s front/rear easy maintainence；
Application:
Wide applied in stage shows,gas station,TV-Show,waiting room of station,parking lot,bar,gym,traffic Control,Highway,cinemas and so on .
Parameter:
| Unit Module | Item | Parameter |
| Model Number | LW-RO3.91 | |
| Module size | 250mm*250mm | |
| Pixel pitch | 3.91mm | |
| Pixels Density | 65536dot/m2 | |
| Pixel configuration | 1R1G1B | |
| LED Package mode | SMD2727 | |
| Pixel resolution | 64dots(W)*64 dots(H) | |
| Max Power | 35W | |
| Weight | 0.65kg | |
| Drive type | Constant drive | |
| Scan mode | 1/13scan | |
| Port type | HUB75-A | |
| Brightness of white balance | ≥4500cd/m2 | |
| LED Cabinet | Dimension | 500mm*1000mm |
| Monomer Module Number | 8 | |
| Power supply | 5V/40A*1pcs | |
| Thermal discharge | fan 1pcs | |
| Pixel per cabinet | 104*208 | |
| Best viewing distance | 5M~20M | |
| Best viewing angle | 160°(W) 120°(H) | |
| Temperature | storage:-35ºC~+85ºC | |
| working:-20ºC~+50ºC | ||
| Relative humidity | 10%-95% | |
| Thickness | 65mm | |
| Power | Working voltage | AC110~220V±10% |
| Average Power consumption | 168W/m2 | |
| Max.Power consumption | ≤560W/m2 | |
| Current | ≤20mA(single LED) | |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
| Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | ≥1920HZ | |
| Grey scale/colors | 4096,16.7M | |
| 4096gray level/16.7M colors | ||
| MTBF | ≥9000hours | |
| Power switch | Automatic switch | |
| Display Mode | ≥800*600/1024*768 | |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | ||
Our service:
- Well-trained and experienced staffs to answer all your enquires in fluent English;
- EXW. FOB. CIF accepted;
- OEM service offered;
- Our products have two years warranty service ,lifetime free maintenance and upgrade;
- Protection of your sales area, ideas of design and all your private information;
Package:
