smd212 indoor high brightness led display stage with S - VIDEO HDMI DVI input Meanwell power

Price Negotiable
Price: Negotiation
MOQ: 1 square meter
Delivery Time: 10-18 working days after received your payment
Brand: Shenzhen LED World
Product Description

P4 smd212 LED Stage Display board indoor with S-VIDEO HDMI DVI input Meanwell power



Features:

  • no fan, zero noise, low power consumption, die-casting aluminum unibody, good heat dissipation on its own;
  • with Slim and small cabinet size of 512× 512× 80mm,It is portable by handed and move to any where,convenient to transport and collect;
  • Auto vertical lock system easier and faster installation and disassembling;
  • Multiform file formats , such as VGA , Video , AVI , MOV , MPG , DAT , VOB and so on are comprehensive;
  • Small panel size and slim thickness, lighe weight, can be picked up by hands;
  • No fan, Lower noise,lower power consumtion,good heat dissipation;
  • Featuring easy vertical stacking for taller fascias and high resolution and wide review angles;
  • the SMD triad technology, makes the screen when use ultra wide Angle of view and better surface smoothness and stability;
  • SMD led encapsulation technology confirm the wide view angle up to 140 degree for horizontal and vertical, and good uniformity,less than 0.1mm difference;





Our service:

  • 1% spare parts offered FOC;
  • All of our LED display have proceeded aging test before shipment,and we guarantee to use our products safety;
  • Delivery time: 10-25 days after receiving the deposit;
  • Under normal use and storage, Our Company will be responsible for the equipments;



Parameter:

P4 SMD2121 Indoor full Color LED Screen Specification
Technical parameters UNIT Parametersvalues
Viewing angle ° H140 V120
Option distance M 4-80
Driving device   2016/5020
Every square metre module PC 30.5
Maximum power W 950
Frame Frequency   ≥60
Refresh frequency   ≥800
Equilibrium brightness CD ≥2000
Working environment temperature -10~60
Working environment humidity   10%~70%
Display working voltage   AC46~54HZ,220V±15%/110V±15%
Colour temperature   6500K-11500K
Gray scale/color   ≥16.7M color
Input signal   RF S-Video RGB etc
Control system   PCTV nonlinearity card,DVI display card,Linsn control system
Mean free error time   >5000
Life Hour 100000
Lampfailure frequency   <0.0001
Antijam   IEC801
Safety   GB4793
Resist the electricity   1500Vlast 1minNo breakdown
die cabinet weight KG 7.2(die cabinet weight)
Earth leakage current   3.5mA
IPrating   The back IP45,The front IP45
Steel box size MM L512XH512X80
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.



FAQ:

  • What is the payment method?
  • We support a variety of payment methods, the most common is the TT;
  • Can it play HD video?
  • Yes, it can realize HD video function with Linsn/nova controlling system;
  • How can i place an order?
  • Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.For designing or further discussion, it is better to contact us with Skype/email /phone, incase of any delays;



Product package:
