P8 iron cabinet Outdoor Fixed LED Display , full hd led full color screen white color
Price:
negotiable
MOQ:
1 square meter
Delivery Time:
10~20 days after receiving the deposit
Brand:
Shenzhen LED World
Product Description
P8 iron cabinet Outdoor Fixed LED Display , full hd led full color screen white color
P8 outdoor fixed led screen display features:
- Rear serviceable；
- The screen is made from high transparent and high intensified acrylic materials and completes after injection molding;
- Can be done with single side or double sides,screen size can be customized if your quantity is larger More pictures for understanding well;
- SMD technology, better color uniformity than DIP. Special design for rental;
- Have obvious competitiveness in quality and price in the international LED market;
- Quick Lock System & PowerCon And EtherCon;
- High protection level IP65;
FQA:
- Where is your company?
- We are located in address:No.4 Bldg,Second Industrial Park of Baiwang,Baimang Village,Xili street,Nanshan District,Shenzhen,China;
- What's the difference between DIP(1R1G1B) and sSMD(One LED, 3 in 1) ?
- SMD(One LED, 3 in 1) LED Display, one pixel has one LED lamp, 3 led chips in one LED Lamp?Traditional DIP( 1R1G1B) use 3 LED Lamp in one pixel.SMD(One LED), reduced the LED on the screens,it reduced grainy of the screen, and improve the Uniform of the screen, this will make the screen have a more wide viewing angle and smooth image.With the technology advanced and SMD brightness improved, SMD is more and more used outdoor;
P8 outdoor led wall display parameter:
| Outdoor Fixed Installed Giant Advertising Media LED Displays | ||
| Main | Pitch/mm | P8 |
| Module size/mm | 256x128 | |
| Density of pixel/(dots/m2) | 15,625 | |
| Pixel composition | 1R1G1B | |
| Led encapsulation | SMD3535 | |
| Resolution of module | 32x16 | |
| Optimum viewing distance | ≥6 | |
| View angle / ° | 140H,120V | |
| Average power consumption/W/M2 | 500 | |
| Max power consumption/W/M2 | 1000 | |
| Size of cabinet/mm | 1024X768 | |
| Resolution of cabinet | 128X96 | |
| Driving method | 1/4 scan constant current | |
| Refresh rate Hz/S | ≥1200 | |
| Luminance of white balance | ≥6000 nits | |
| Operation of Environmental Temperature/℃ | below 30 to above 50 | |
| IP rating | Front,IP65;Rear,IP43 | |
| Working voltage | 110-220 VAC/+/- 10% | |
| Grey scale/color | displaying colors≥16.7M(synchronized) | |
| Brightness adjustment | 4096 levels of each color(manually),100 levels of each color(automatically) | |
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc | |
| Control system | Linsn / Nova(sending card,receiving cards and Hubs) | |
| Average of non-failure life | >50,00h | |
| Life span | >100,000h | |
| Functionless dot rate | <0.0001 | |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | ||
Why choose us:
- 100% QC inspection before shipping;
- Excellent R&D team,lower the cost and assure you quality goods;
- Competitive price as stocks and lower marketing expense;
- Our products are the CE certified, ROHS compliant, FCC identified;
- Good quality by using Nationstar led lamp, MBI IC;
