P10 Dip Rental And Fixed Outdoor Led Display Screen With 960 X 960 Mm Cabinets
Price:
negotiable
MOQ:
1 square meter
Delivery Time:
10~20 days after receiving the deposit
Brand:
Shenzhen LED World
Product Description
P10 Dip Rental And Fixed Outdoor Led Display Screen With 960 X 960 Mm Cabinets
P10 outdoor rental and fixed LED panel features:
- Long durability and Hight Reliability；
- Saving time and labor: once the screen is installed successfully, the advertising content can change at any time as request, don't like the traditional static billboards need to be dissambled frequently, save the working time and labor cost, and control the advertising contents easily;
- General configuration: branded led lamp chip, branded driving IC;
- Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously；
- Thanks to the SMD 3 in 1 technology, the viewing angle is ultra wide and the screen’s surface even flatter;
- Support different image and video formats.
- Flash, WAV/MIDI, Videos from TV and other equipments;
- IP65 waterproof;
- Perfect for outdoor usage;
Parameter:
| Model | LW-F 10 Outdoor Fixed LED Display |
| Pixel pitch | 10,12,16,20mm |
| LED Encapsulation | DIP |
| Pitch Composing | DIP |
| Module Size | 320mm*160mm |
| Module Resolution | 16dot*8dot |
| Cabinet Size | 960mm * 960mm *105mm |
| Cabinet Resolution | 48dot*48dot |
| Cabinet Material | Die-casting |
| Cabinet Weight | 25kg |
| Density | 10,000dot/S.Q.M |
| Brightness | ≥8000nits |
| Brightness Adjustment | Auto 256 level |
| Viewing Distance | 15m-300m |
| View Angle(H) | 150° |
| View Angle(V) | 140° |
| Average Consumption | 300W/ |
| Max Consumption | 600W/ |
| Brightness Adjustment | Manual/Auto/Programmable |
| Driving Method | 1/8 Scan Constant Driving |
| MTBF | 50000hours |
| Lifespan | 100000hours |
| Frame Frequency | 60Hz |
| Working Temperature | -20ºC+50ºC |
| Humidity Range | 10% ~ 90% |
| Voltage | 110 ~ 240V |
| IP Ranking | IP65 |
| Signal Type | AV,S-Video,VGA,DVI,HDMI,SDI,DP |
| Tranmission Distance | UTP:100 meters; single-mode fiber: 10 km |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |
Our service:
Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection;
Top quality+Reasonable price+Responsible After Service=Successful & Win;
Warranty: 2 years;
Customer can send your engineer who has electronic and computer knowledge to our factory for the operation and maintenance training;
FQA:
- May I know the package details?
- For fixed installation, we use wooden case, usually 2 or 4 cabinets in 1 wooden case;For rental market, we suggest you use flight case, generally 8 cabinets in one flight case.It's safe to protect the screen on the way, also economical;
- What's the pixel pitch for Outdoor LED Display Screen?
- Outdoor(p3.91mm/p4.81/p5mm/P6mm/p6.25/p6.67/ P8mm/P10mm/p16mm/p20mm) led display screen;
- May I know the Minimum order for your products?
- For our products, no limit for the size of the screen, but generally speaking, one screen the dots more than 50000 dots will be clear for the audience to see the video on the screen;
