P6 14 Bit Gray Grade Indoor Rental Led Display Video Wall With Epstar And Silan Chip
- P6 indoor rental LED display screen panel board with Slim body & light weight, Easy maintenance, Long use life;
- Show all kinds of word, text, graph, pictures, flashes, video, 2-dimension, 3-dimension cartoon and any other formats with your PC does synchronously;
- Standard panel design makes stocking, transportation, construction, spare parts and maintenance easy and simple;
- Die-casting aluminum, good heat dissipation ;
- High structure performance: easy connection of each components, modules and HUB card without flat cables, modules and systems without power cable.
Application:
Our full color LED display are widely used in Indoor stage,plaza,chain shop,enterprise engineering, hotels,Entertainment complexes,park,stadiums,stage background,government agencies,traffic display,Government facilities,Building facilities,theaters,event and so on .
Parameter:
| Item | P6 |
| Chip | Epstar + Silan chip |
| Chip size | Red 9 mil, Green 12. Blue 12mil |
| Light type | SMD |
| Pixel Pitch | 6mm |
| Module Size | 192mmX192mm |
| Module Resolution | 64 X 32 (dots) |
| Density of pixel | 27777dots/m2 |
| Pixel configuration | 1R1G1B |
| Red wavelength | 625±2nm |
| Green wavelength | 525±2nm |
| Blue wavelength | 470±2nm |
| Colors | 16777216 |
| Best viewing distance | ≥4m |
| viewing angle | 120°/90° |
| Maximum power consumption | 20W |
| Brightness | 2000cd/m2 |
| Gray scale | 14bits per color |
| Color temperature | 6500k |
| Control method | Synchronization or Asynchronization |
| Driving method | 1/16 scanning |
| Frame frequency | 60Hz |
| Refresh frequency | ≥600Hz |
| Working Voltage | DC5V |
| IP grade | IP54 |
| MTBF | More than 8000hours |
| Life Span | 80,000hours |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |
- No MOQ;
- Top quality + reasonable price + patient after-sales service;
- Our products are the CE certified, ROHS compliant, FCC identified;
- CE,RoHS,FCC, ISO9001;
- Service advantage: Better service at same situation, better cooperation at same service;
- Excellent R&D team,lower the cost and assure you quality goods;
Our company:
Our company is professional in the development and manufacture of LED display systems.
Its outdoor & indoor commercial advertising LED display, rental use LED display, fixed installation LED display, sports stadium perimeter LED display, mobile trailer LED display, water floating LED display, transparent LED curtain display, digital LED billboard, LED mesh display screen for skyscraper's decoration, arc LED display, LED components & complete LED full color video systems undergo stringent quality control at ISO 9001-certified manufacturing plants.
Project case:
