SMD3535 High Accuracy outside rental led screen with 640x640 die caste cabinet
Price:
negotiable
MOQ:
1 square meter
Delivery Time:
12~20 working days after deposit received
Brand:
Shenzhen LED World
Product Description
SMD3535 High Accuracy outside rental led screen with 640x640 die caste cabinet
Quick detail:
- Scan driver:1/4 current;
- Module size(L*W):256*128mm;
- Pixel pitch:8mm;
- Pixel constitute:1R1G1B;
- Pixel density:15625dots/sqm;
- Quantity:245 pcs die-caste cabinet ;
- Date:3the March 2017 ;
- Size:100.35 square meter
Description:
- Reliable quality, advanced and mature technology,compliant with industrial standards and technology developing trend;
- High reliability: Average time between failures(MTBF)is 2 years at least;
- Easy installation and maintenance ;
- Energy consumption: using 4.5 switching power supply, saving 10% of power consumption. actively respond to the national energy conservation and emission reduction policies;
- Ultra thin body, easy to transport and loading and unloading ;
- It is die-casting aluminum cabinet, very strong and precision is very high, tolerance can be controlled in 0.1mm so the surface is very smooth, almost no gap between cabinets.
Parameter:
| NO. | Parameter | Specification |
| 1 | Model | LW-RO8 |
| 2 | Pixel Pitch(mm) | 8 |
| 3 | Pixel Density | 15625dots/sqm |
| 4 | LED Type | SMD3535 |
| 5 | Viewing Angle | horizontal 140°,Vertical 140° |
| 6 | Brightness | ≥5500cd/sqm |
| 7 | Drive Method | 1/4 scan |
| 8 | Color Depth | 14bit |
| 9 | Refresh Rate(Hz) | ≥1920 |
| 10 | Frame Frequency (Hz) | ≥60 |
| 11 | Brightness Adjustment | Manuel/Auto/Remote control |
| 12 | Module Size(mm) | 320×160×17 |
| 13 | Module Resolution(dots) | 40×20 |
| 14 | Cabinet Size(mm) | 640×640×80 |
| 15 | Cabinet Resolution(dots) | 80*80 |
| 16 | Cabinet Type and Material | Die-casting Aluminum |
| 17 | Cabinet Weight(Kg) | ≤12 |
| 18 | Voltage(V) | AC 100~240V |
| 19 | Avg. Power Consumption | 391W/sqm |
| 20 | Max. Power Consumption | 850W/sqm |
| 21 | Service Access | Rear Access |
| 22 | IP Grade | Front: IP65 / Rear: IP54 |
| 23 | Operating Temp/Humidity | -30ºC~60ºC, 10~95%RH |
| 24 | Storage Temp/Humidity | -40ºC~60ºC, 10~95%RH |
| 25 | Lifetime(Normal Temp) | ≥50000H |
| 26 | System Controlle | Linsn/Novastar |
| 27 | Compliant Standard | CCC/CE/RoHS |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | ||
- Maintenance principles: response in time, solve problems as soon as possible and ensure the use
- Under normal use and storage, Our Company will be responsible for the equipments;
- Your inquiry will be replied within 24 hours!
- Lifetime free maintenance and upgrade;
Application:
Wide applied in securities exchange, museums ,Football fields,telecommunications,elevator,railway stations,
studio,big square,entertainment TV,financial securities,Shopping area,industrial park and so on.
Project case:
