SMD3535 Led Video Wall Rental , Led Wall Rental Constant Drive Easy Install
Price:
negotiable
MOQ:
1 square meter
Delivery Time:
12~20 working days after deposit received
Brand:
Shenzhen LED World
Product Description
Die-casting LW-RO4 Rental Outdoor LED Display with 512x512mm cabinet
Quick detail:
- Pixel pitch: PH 4mm ;
- Pixel density:62500 dots/M2 ;
- Module size: 256x128 mm ;
- Cabinet size:die-casting 512 x 512 mm ;
- Drive mode:1/16 scan ;
- Brightness:5000cd/m2 .
Product description:
- The use of fast lock structure, the screen is easy to install, remove and repair;
- Products use sealed structure, with good waterproof, dustproof performance ;
- Our products are highly refreshed, up to 1920HZ above, suitable for TV video or take pictures ;
- Our brightness automatically adjust and use with PFC power to make the screen low power consumption;
- Usually we use Epistar + Silim LED from Taiwan configuration ;
Product specification:
| Item | Parameter | Parameter |
| Module | Model No | LW-RO4 |
| Module size | 256mm*128mm | |
| Module resolution | 64 dots * 32 dots | |
| Pixel pitch | 4mm | |
| cabinet | Cabinet Dimension | 512mm*512mm |
| Module Quantity | 8pcs | |
| Cabinet Resolution | 128*128 | |
| Cabinet Material | Die Casting Aluminum for rental purpose | |
| Electricityparameter | Pixel Density | 62500 pixels/m2 |
| Pixel configuration | 1R1G1B | |
| LED Package mode | SMD2525 | |
| Drive type | Constant drive | |
| Scan mode | 1/16 scan | |
| Port type | HUB75-A | |
| Brightness of white balance | ≥5000cd/m2 | |
| Best viewing distance | 4M~15M | |
| Best viewing angle | 120°(H) 120°(V) | |
| Average Power consumption | 400W/m2 | |
| Max.Power consumption | ≤1000W/m2 | |
| Current | ≤20mA(single LED) | |
| Frame Frequency | 50-60Hz | |
| Refresh frequency | ≥1920HZ | |
| Power Supply Mode | AC220±10% 50Hz/AC110±10% 60Hz | |
| Temperature | storage:-35ºC~+85ºC | |
| working:-20ºC~+50ºC | ||
| Humidity | 10%-95% | |
| Grey scale/colors | 256levels of each color(RGB)/16.7M colors | |
| Screen Lifespan | ≥100,000 hours | |
| Screen Plainness | <±1mm | |
| Blind Spot Rate | <0.0001 | |
| CPU | Pentium4 or above | |
| Operation system | WIN98/2000/NT/XP | |
| Control method | Synchronization | |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | ||
Application:
Our products are used in athletic contest,museums, travel agencies,financial industry,shopping mall,pedestrian streets,station waiting area, station weiting area, coffee shop,shopping malls, restaurants, Government facilities,school, stores, meeting room,large shopping mall and so on .
Our service:
- OEM service offered;
- We only offer the drawings, and you can show the drawing to your local steel structure factory, and they will weld it for you at site. On one hand, it's not cost-effective for you to ship the steel structure from China. On the other hand, we are impossible to offer you exact steel structure without welding at site;
- We provide detailed CAD drawing to customer to prepare metal structure;
- We provide customer service through Skype, phone or email, provide video or drawing to solve customer's problem;
- Warranty: 24 month quality guarantee.After 24 months, only charge for the cost of the repair. During the 24 month warranty time, we will be responsible for any damage happened to the display because of the quality fault, not wrong operation. As soon as we confirm that the damage is not caused by manual operation fault, we will deliver the good parts to you by air within 3 days for replacement. After 12 months, we can also offer you the parts for replacement at our bottom price
- Factory and product inspection accepted;
Project case:
