HD P1.875 Indoor LED Display Screen 1000cd/m2 Brightness Ultrathin Cabinet
HD P1.875 indoor LED display screen with ultralight and ultrathin cabinet
HD P1.875 indoor LED display screen features:
- High precision die-casting aluminum cabinet design for 2K / 4K standard size screen;
- Seamless splice: no space/gap between the cabinet, ensure the good information;
- Panel with 16:9 each, for good display vision;
- With pure black 1515 led, perfect color consistency, dot to dot matching 1920 x 1080/3840 x2160 2K/4K resolution for the best display result;
- Low brightness and high gray level (16bit), high color revivification degree;
- Pure image with great gradation brings delicate display effect;
HD P1.875 indoor LED display screen parameter:
| Product name | P1.875-32S indoor LED display |
| Pixel pitch | 1.875mm |
| Unit plate size | 240*120(mm) |
| Unit box size | 480*480(mm) |
| Physical density | 284444dot/m2 |
| Pixel configuration | 1R1G1B |
| Panel resolution | 128*64=8192 DOTS |
| Box resolution | 256*256 |
| Box area | 0.2304m2 |
| Die casting aluminum weight | 7.9KG±0.05KG |
| Main technical parameters | |
| Best visual range | 2m~30m |
| Level of viewing Angle | >=160° is optional |
| Vertical | 140 ° or more optional |
| The average power consumption | <400 w / m2 |
| The maximum power consumption | <800 w /m2 |
| Control mode | Synchronization control |
| Display card | 1/32 scan |
| Maximum power | no more than 40W |
| Refresh rate | 60Hz |
| brightness | >= 1000cd/m2 |
| Frame switching frequency | >=2880Hz |
| Brightness adjustment | brightness induction ,automatically adjusts 16 levels of adjustable |
| Software manual adjustment | 100 level adjustable 100 |
| Computer operating system | WIN98, WINXP, WIN2000,etc |
| Video signal | RF, s-video, RGB, RGBHV, YUV, YC, etc |
| Control system | PCTV card (optional optional optional) +DVI video card + master control card + optical fiber transmission (optional optional optional) |
| Life expectancy | 75,000 ~ 100,000 hours |
| Pixel out of control rate | < 0.0002 pieces |
| Project category | PH1.875-32S |
| Packaging | three in one |
| LED packaging | 1515 |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |
Our service:
- Responding time: upon receiving user’s notification, we ensure 24-hour after-sales technical support;
- We guarantee all our display, modules, spare parts (Silan Chip) for TWO years;
- Maintenance principles: response in time, solve problems as soon as possible and ensure the use；
- Software Upgrade: lifelong maintenance of control system, the incessant improvement on the system functions and unending software upgrades；
- We guarantee all our displays, modules, parts for two full years. During this time, we will replace or remand our goods for free if there is something wrong with them；
FQA:
Q1: What is the request for the power supply of P4.81 video wall?
A1: The LED display screen is the big size precision equipment. To operate in security and stability, the AV 220V power supply input port of the LED display screen or the connected computers power supply input port need to connect with the ground.
Q2: What about the lead time for the order?
A2: Always: 7-20 days, as your order quantity, sometimes we have stock, can delivery within 7 days;
Q3: What is front maintenance, what is rear maintenance? How to choose the best servicing model for your LED display system?
A3: Front maintenance has two means to achieve: module front maintenance cabinet front maintenance;
Q4: Where is your factory located? How can I visit there?
A4: Our factory is located in Shenzhen City, Guangdong Province, China;
Project detail:
