Automatic Hospital ICU Room Door
Automatic Icu Room Door Hospital Sliding Doors With Viewing Window
Automatic Sliding Doors for Operating Theatres, ICU / NICU / HDU
1. The door body is made of colorized steel panel with foaming process or made of the large-plane sub-light stainless steel plate and framed large-plane glass;
2. At both sides and the center joint, there are the sealing strips installed, which conforms to the sanitary requirement for use in hospital, research institute, recording studio or any other places need for dustproof and cleanness;
3. The dodge gate is equipped with rubber seal. Special purpose seal stripe are used to seal around th emobile door to make sure that the door will joint tightly with the doorframe for air tightness when closed;
4. It can joint the door frame when closedown. and ensuring the airtightness of door;
Standard size and specification :
| Door material for outside |
Color painted steel, stainless steel (SUS), aluminum, PVC, fireproof board, etc. |
|
| Door frame material | Stainless steel, aluminum | |
| Knock blade material | Stainless steel | |
| Seal material | Silica gel, rubber | |
| Door lock & door hinge material | Stainless steel | |
| Door skin color |
Original SUS color, original aluminum color, light blue, white, gray, beige, etc.are available |
|
| Door size | swing door |
Single door width: 700mm - 1000mm Mother & son door width: 1200mm - 1400mm Double door width: 1400mm - 1800mm Door height: 1900mm - 3000mm |
| sliding door |
Single door width: 1000mm - 2200mm Double door width: 1500mm - 3000mm Door height: 1900mm - 3100mm |
|
| Automatic door system |
Opening door by hand sensor switch, feet sensor switch or press switch |
|
| Door advantage | Airtight, easy clean and antibiosis | |
Customized size is available
