26er Am/Enduro Full Suspension Mountain Bike Frame 153MM travel MTB frame AL7005 Aluminum
Price:
US$800-900.00/UNIT
MOQ:
1 UNIT
Delivery Time:
3-7 working days for ready goods, 30-45 days for OEM order
Brand:
KINESIS
Product Description
26er Am/Enduro Full Suspension Mountain Bike Frame 153MM travel MTB frame AL7005 Aluminum
New KINESIS KSM636 Frame
Product Description
KINESIS have SPF technique,even the world’s bicycle experts "recommend Kinesis SPF Tubes"
1.Superplastic Forming Technique
SPF MEANS SUPERIOR PERFORMANCE AND FUNCTION
SPF allows better tube shapes that cannot be produced using traditional forming techniques. Whereas shape designs can be applied to 20% - 30% of the tube using hydroforming, SPF allows up to 90%. In addition, complex shapes will not compromise the tube’s structural strength unlike hydroforming.
The result: more optimized shapes and lesser weight. SPF tubes are 10% lighter than hydroformed tubes at 20% transformation. 25% lighter at 30% transformation.
THE FIRST ONE!
KINESIS is the first and only bicycle frame factory capable of utilizing SPF to its full potential!
2.Superlight
Engineered for maximum lightness with no compromise in overall frame strength. Kinesis Superlight tubes deliver a total frame weight reduction of 362 grams compared to plain-gauge aluminum tubing when used on a 19-inch MTB chassis.
Technical Data:
| Product | Full Suspension Mountain Bike Frame |
| Material | Aluminum Alloy AL7005. |
| Brand | Kinesis |
| Model | KSM636 |
| SIZE | M/17.5" |
| Color | Black & Green |
| Headset | Tapered,1 1/8"-1 1/2" |
| Seat post | Ø31.6mm |
| Front derailleur | D-Type direct mount |
| Chain guide | ISCG03 |
| Cable routing | Inner cable routing |
| Bottom bracket | Press-fit L90mm |
| Brake | Disc brake direct mount |
| Wheelset | 26"x2.35" |
| Rear shock travel | 200-22-22(24.5) |
| suggestion outside diameter of champer not more than Ψ42mm | |
| Rear drop out | 142xØ12mm |
| Travel of rear shock | 6" |
| Riding Style | Am/Enduro |
Configuration: Frame only
Support the line of suspension seat post
Suggested length of oil tube:1700mm
Package includes
| Frame | 1 pc |
| Headset | 1 set |
| Seatpost clamp | 1 pc |
| Oil pipe clamp | 1 set |
| Rear shock | Not included |
Shipping info
WORLDWIDE SHIPPING by EMS.
Combine shipping, please mail me for quote.
Many countries customs require taxes for imported items.
So we always declare items as "Bike Frame" with LOW VALUE.
