Bafang M620 1000W E-bike Frame Mid-Drive Pedelec EMTB Electric Bike
Price:
usd185-220
MOQ:
100 pieces
Delivery Time:
45-60 days after order confirmation
Brand:
OEM
Product Description
Bafang M620 1000W E-bike Frame Mid-Drive Pedelec EMTB Electric Bike
Features:
1.Robust in power: fit with bafang g510(m620) 1000w(48/52v) mid-drive motor. Max. Torque:160n.m
2.Big Capacity Integrated Battery Pack: 80 cells 18650 or 60 cells 21700 can get 48v/21ah(1008wah) or 52v/20ah(1040wah)
3.Wide Tires applicable 29er boost version with max tire 27.5x2.80 or 29x2.40.
Technical Data:
| Name | 29er boost 1000w mid-drive e-bike frame |
| Material | Aluminum Alloy AL6061,T4/T6 heat treatment |
| Model | LDE6035 |
| Motor | Bafang G510/M620 1000w Mid-drive motor ,48/52v |
| Battery Pack | Intergrated 52v/1040ah or 48v/1008ah. |
| Size | 17, 19", 21" |
| Dropout | 148x12mm thru-axle |
| Max.tire | 29x2.40 or 27.5x2.80 |
| Brake | Disc Brake, Post mount |
| Seatpost | 31.9mm |
| Headset | Tapered (44/56mm) |
| Routing | Internal cable routing( RC external routing) |
| Weight | 3.8kg(19") |
| Rear carrier | attachable |
| Riding style | pedelec emtb, enduro ebike |
| OEM | Acceptable |
| Sample | Available(Please confirm with us) |
Terms
Quality Stand: ISO9410
Warranty: 2 years
Payment: 50% deposit and balance before shipment.
Sample: available
Shipment: By sea/ By express
